Client PCs

2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

M.2 (2280)

PCIe Gen 3.0 x4, NVMe 1.3

80.15 x 22.15 x 2.38 (mm)

Max 8.0 g Weight

Samsung V-NAND 3-bit MLC

Samsung in-house controller

Samsung 2GB Low Power DDR4 SDRAM

Supported

Supported

Auto Garbage Collection Algorithm

AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)

Not supported

Yes

Up to 3,500 MB/s * Performance may vary based on system hardware & configuration

Up to 3,300 MB/s * Performance may vary based on system hardware & configuration

Up to 620,000 IOPS * Performance may vary based on system hardware & configuration

Up to 560,000 IOPS * Performance may vary based on system hardware & configuration

Up to 19,000 IOPS * Performance may vary based on system hardware & configuration

Up to 62,000 IOPS * Performance may vary based on system hardware & configuration

*Average: 6 W*Maximum: 9 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration

Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration

3.3 V ± 5 % Allowable voltage

1.5 Million Hours Reliability (MTBF)

0 - 70 ℃ Operating Temperature

1,500 G & 0.5 ms (Half sine)

Not Available

Magician Software for SSD management

5-Year Limited Warrantyor 1,200 TBW Limited Warranty
