Back Ports and VESA screw hole specs: Q60B 43-70 inch
The ports are located on the back, to the left.
Back ports
VESA and screw specs
| VESA (A) x (B) (mm) | (C) (mm) | (D) | (E) x 4 | (F) (mm) | (G) (inches) | (H) (inches) | (I) (inches) | |
| QN43Q6*B | 200 x 200 | 11-13 | (C) + * | M8 | 1.25 | 7.6 | 15.1 | 6.6 |
| QN50Q6*B | 8.2 | 18.1 | 9.3 | |||||
| QN55Q6*B | 9.4 | 20.3 | 10.6 | |||||
| QN60Q6*B | 400 x 300 | 8.2 | 18.8 | 10.5 | ||||
| QN65Q6*B | 10.4 | 20.7 | 10.5 | |||||
| QN70Q6*B | 9.6 | 22.8 | 14.1 |
* : Wall-Mount Bracket
