8 720 TVL High Resolution, True Day & Night, Weather-Resistant Cameras
16 Channel 960H DVR & Built-In 1 TB HDD
Get Stock Alerts
May we send you an alert when this product is available?
Let's keep in touch! Tick the box to receive promotional email and texts (which may be autodailed) from Samsung Electronics America to the number provided above.The Samsung Privacy Policy explains how we use your information. You do not have to consent to receive text messages to receive any product or services from us. Messaging and data rates may apply.
Log in now to earn up to %
back in Samsung Rewards Points
Global Download Center
SAMSUNG assumes no responsibility, and shall not be liable, in connection with whether any such products or services will be appropriate, functional or supported for the SAMSUNG products or services available in your location.
How to register a Samsung product with your Samsung account
Set up and connect the ADT Carbon Monoxide Alarm
Power Consumption
System Weight (with Hard Disks)
Weight
Focal Length
Anytime/Anywhere
Samsung’s free iPOLis mobile app brings surveillance video right to your iOS® or Android™ tablet or smartphone. To oversee multiple systems in various locations, Samsung's central management software, Smart Viewer®, allows video monitoring from all points around the globe on a single screen.
Event/Tampering Alerts
Instant email notifications can be sent when motion or camera tampering is detected and automatically recorded onto the DVR. Guarding your safety, Samsung empowers you to respond instantly to unexpected events, view real-time activity and review stored recordings.
Sharp, Rich Details
The cameras provide up to 720 TVL resolution for clear, vivid image quality. In keeping with this high standard, the DVR records at 960H high resolution onto a 1TB hard drive to capture all of your important video events.
Wide Angle Coverage
While other cameras constrict your view, Samsung’s 72° Wide Angle lens expands your recording coverage without compromising quality.
True Day & Night
Each SDS-P5082 camera utilizes an advanced IR Cut Filter for accurate, vibrant colors and Night Vision mode to capture clear, illuminated footage up to 82 feet in darkness.
Privacy Masking
Privacy Masking allows you to block up to four areas within each camera’s field of view. This advantage lets you tailor your monitoring to exclude sensitive areas or conceal irrelevant or personal activity.
Weather-Resistant
Every camera in the SDS-P5082 system has achieved an Ingress Protection Rating of IP66. Rest assured that they have been tested to withstand dust, wind and rain.
Easy Setup/Upgrade
DVR setup is intuitive and simple and can accommodate eight additional cameras. Samsung’s optional WiFi adapter eliminates the need for network cable connection. This liberates DVR placement away from the router to your most suitable location within WiFi range.
Features and specifications are subject to change without prior notification
-
Video Display Inputs
16 Composite video
Resolution
Video: NTSC : 960 x 480, 720 x 480 / PAL : 960 x 576, 720 x 576
Live: NTSC : 960 x 480 / PAL : 960 x 576 -
Live Display Frame Rate
NTSC : 480fps / PAL : 400fps
Multi Screen Display
1 / 4 / 6 / 8 / 9 / 13/ 16 / Sequence / PIP
-
Operating System Embedded
Linux
-
Recording Compression
H.264
Record Rate
NTSC : Up to 480fps@960 x 480 / PAL : Up to 400fps@960 x 576 NTSC : Up to 480fps@704 x 480 / PAL : Up to 400fps@704 x 576 NTSC : Up to 480fps@704 x 240 / PAL : Up to 2400fps@704 x 288NTSC : Up to 480fps@352 x 240 / PAL : Up to 400fps@352 x 288
Mode
NTSC : Manual, Schedule (Continuous/Event), Event (Pre/Post), Time Lapse (1~30fps)PAL : Manual, Schedule (Continuous/Event), Event (Pre/Post), Time Lapse (1~25fps)
Overwrite Modes
Stop / Continuous
Pre-alarm
Off / 5sec
Post Alarm
Up to 6 hr (5,10, 20, 30 sec, 1, 3, 5, 10, 20 min, 1, 2, 3, 4, 5, 6 hr)
-
Search & Playback Search Mode
Date/Time, Event, Back up, Motion
Playback Function
Fast forward / backward, Slow forward / backward, Step forward / backward
-
Network Transmission Speed
960H / 4CIF / 2CIF / CIF (NTSC : 480fps, PAL : 400fps)
Bandwidth
Up to 32Mbps, 2 / 1.5 / 1Mbps / 800 / 600 / 500 / 400 / 300 / 200 / 100 / 50kbps
Bandwidth Control
Automatic
Stream
H.264 (4CIF / 2CIF / CIF Selectable)
Max. Remote Users
10 persons (Search up to 3 / Live unicast / Live multicast available)
Protocol Support
TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP, SNMP
Monitoring
SmartViewer, Webviewer, Mobile Viewer
-
Smart Phone Smart Phone
Supported / Web / App Viewer
-
Storage Internal HDD
1 TB SATA
USB (Back up)
2 USB ports
File Format (Back up)
BU (DVR player), EXE (Includes player), AVI
-
Security Password Protection
1 Admin, 10 Group, 10 User per 1group
Data Authentication
Watermark
-
Monitor Interface VGA / HDMI
1 VGA (1280 x 720, 1280 x 1024, 1920 x 1080) / 1 HDMI (1280 x 720, 1280 x 1024, 1920 x 1080)
Simultaneous Output
VGA and HDMI
-
Audio Interface Inputs / Outputs
4CH line In / 1CH line out
Compression
G.711
-
Alarm Interface Remote Notification
Notification via e-mail
-
Connections Ethernet (LAN)
1 RJ-45 10/100Mbps Base-T
USB
USB 2.0, 2 ports (Front/Rear)
Application Support
Mouse, Remote control
Protocol Support (RS485)
Samsung-T/E, Pelco-D/P, Panasonic, Phillips, AD, VICON, GE
Wi-Fi Connectivity
Optional with Samsung USB WiFi adapter
-
Electrical Input Volltage / Current
12V DC adapter, 100 ~ 240V AC ±10%, 50/60Hz
Power Consumption
Max. 36W (With 1x HDD)
-
Environmental Conditions Operating Temperature (F)
0°C ~ +40°C (+32°F ~ +104°F)
Humidity
20% ~ 85%RH
-
Dimensions System Dimensions (WxHxD)
12.4" x 2.05" x 8.82"
-
Weight & Dimensions System Weight (with Hard Disks)
3.73 lbs
-
Languages Languages
English, Spanish, French, German, Italian, Polish, Portuguese, Russian,Turkish, Japanese, Czech, Swedish, Danish, Korean, Chinese, Netherland, Thai, Romanian, Serbian, Croatian, Hungarian, Greek
-
Camera Input Voltage
12V DC
Power Consumption
3 W
Imaging Device
1/3" 960H CMOS
Scanning System
Interlace
Frequency
H: 15.734Hz / V: 59.94Hz
Horizontal Resolution
720TV lines / Color : 7Lux
Min. Illumination
0Lux (IR LED)
S/N Ratio (Y Signal)
46dB
Shutter mode
Auto (Rolling shutter)
Gain Control
Auto
White Balance
Auto (1,800°K ~ 10,500°K)
Digital Noise Reduction
Auto
Day & Night
Mechanical: Auto (ICR)
IR Distance
25m (82ft)
Operating Temperature
-10°C ~ +50°C (+14°F ~ +122°F)
Humidity
20% ~ 85% RH
Igress Protection
IP66
Dimensions (WxHxD)
2.84" x 2.48" x 7.57"
Weight
0.55 lbs
-
Lens Focal Length
3.8 mm
Max.Aperture Ratio
F2.0
Angular Field of View
H : 60˚ / V : 48˚ / D : 72˚
