SDH-P5081 8 Camera, 16 Channel 1080p Hybrid DVR Security System
![](https://image-us.samsung.com/SamsungUS/pim/migration/smart-home/home-monitoring/security-systems/sdh-p5081/Pdpdefault-sdh-p5081-600x600-C1-052016.jpg?$product-details-jpg$)
![](https://image-us.samsung.com/SamsungUS/pim/migration/smart-home/home-monitoring/security-systems/sdh-p5081/Pdpdefault-sdh-p5081-600x600-C1-052016.jpg?$product-details-jpg$)
- Images must be in BMP, PNG, GIF or JPEG format.
- File size must be 5 MB or less.
- Image must be at least 100 pixels tall.
- Image must be at least 100 pixels wide.
- It contains copyrighted media (and you don't hold the copyright)
- It contains media not related to the product
We may not publish your review if:
- It contains copyrighted media (an you don't hold the copyright)
- It contains media not related to the product
4 1080p Full HD & 4 720 TVL Resolution, Weather-Resistant Cameras
16 Channel (4 Full HD) (12 SD), DVR with Built-in 2 TB HDD
Get Stock Alerts
May we send you an alert when this product is available?
Let's keep in touch! Tick the box to receive promotional email and texts (which may be autodailed) from Samsung Electronics America to the number provided above.The Samsung Privacy Policy explains how we use your information. You do not have to consent to receive text messages to receive any product or services from us. Messaging and data rates may apply.
![Samsung Reward Points](http://image-stgus.samsung.com/SamsungUS/PIM/reward_samsung_care.png)
Log in now to earn up to %
back in Samsung Rewards Points
Global Download Center
SAMSUNG assumes no responsibility, and shall not be liable, in connection with whether any such products or services will be appropriate, functional or supported for the SAMSUNG products or services available in your location.
How to register a Samsung product with your Samsung account
Set up and connect the ADT Carbon Monoxide Alarm
Input Voltage
USB (Back up)
System Weight (with Hard Disks)
Compression
Anytime/Anywhere
Samsung’s free iPOLis mobile app brings surveillance video right to your iOS® or Android™ tablet or smartphone. To oversee multiple systems in various locations, Samsung's central management software, Smart Viewer®, allows video monitoring from all points around the globe on a single screen.
![Anytime/Anywhere](http://image-us.samsung.com/SamsungUS/pim/migration/feature/part13/iPOLiSapp_1_SDH-P5081.jpg?$feature-benefit-jpg$)
![Event/Tampering Alerts](http://image-us.samsung.com/SamsungUS/pim/migration/feature/part9/EventNotification_2_SDH-P5081.jpg?$feature-benefit-jpg$)
Event/Tampering Alerts
Instant email notifications can be sent when motion or camera tampering is detected and automatically recorded onto the DVR. Guarding your safety, Samsung empowers you to respond instantly to unexpected events, view real-time activity and review stored recordings.
Vibrant 1080p Full HD
This hybrid DVR supports the four 1080p Full HD cameras and the four analog cameras, recording in both 1080p Full HD and up to 960H high resolution. Producing the clearest, most vivid image quality, it stores video onto a 2 TB surveillance class hard drive.
![Vibrant 1080p Full HD](http://image-us.samsung.com/SamsungUS/pim/migration/feature/part10/FullHD_3_SDH-P5081.jpg?$feature-benefit-jpg$)
![Wide Angle Coverage](http://image-us.samsung.com/SamsungUS/pim/migration/feature/part21/WideAngle_3_4_SDH-P5081.jpg?$feature-benefit-jpg$)
Wide Angle Coverage
Maximize your monitoring power with Samsung’s 103° Ultra-Wide Angle lens*. Expand your view without sacrificing crisp, clear details.
True Day & Night
Each camera utilizes an advanced IR Cut Filter for accurate, vibrant colors and Night Vision mode to capture clear, illuminated footage up to 98 feet in darkness.
![True Day & Night](http://image-us.samsung.com/SamsungUS/pim/migration/feature/part20/TrueDayNight_4_5_SDH-P5081.jpg?$feature-benefit-jpg$)
![Privacy Masking](http://image-us.samsung.com/SamsungUS/pim/migration/feature/part17/PrivacyMasking_6_SDH-P5081.jpg?$feature-benefit-jpg$)
Privacy Masking
Privacy Masking allows you to block up to four areas within each camera’s field of view. This advantage lets you tailor your monitoring to exclude sensitive areas or conceal irrelevant or personal activity.
Weather-Resistant
Every camera in this system has achieved an Ingress Protection Rating of IP66. Rest assured that they have been tested to withstand dust, wind and rain.
![Weather-Resistant](http://image-us.samsung.com/SamsungUS/pim/migration/feature/part21/Weatherproof_2_7_SDH-P5081.jpg?$feature-benefit-jpg$)
![SSDR](http://image-us.samsung.com/SamsungUS/pim/migration/feature/part19/SSDR_8_SDH-P5081.jpg?$feature-benefit-jpg$)
SSDR
High contrast or backlit scenes pose no problems. Samsung Super Dynamic Range (SSDR) automatically lightens the dark areas without altering the brighter ones. This ensures that shadows are no obstacle to reliable monitoring.
Samsung Quick Connect
Setting up remote viewing is a snap. Simply plug your internet connection into the DVR and let the Quick Connect technology find your router and set the network configuration automatically.
![Samsung Quick Connect](http://image-us.samsung.com/SamsungUS/pim/migration/feature/part9/EasySetUp_1_9_SDH-P5081.jpg?$feature-benefit-jpg$)
Features and specifications are subject to change without prior notification
-
Video Display Inputs
4 CH UTP, 12CH BNC Composite video
Resolution
Video -
NTSC : 1920 x 1080, 960 x 480
PAL : 1920 x 1080, 960 x 576,
Live -
NTSC : 1920 x 1080
PAL : 1920 x 1080 -
Live Display Frame Rate
NTSC : 120 fps @ 1920 x 1080, 360 fps @ 960 x 480
PAL : 100 fps @ 1920 x 1080, 300 fps @ 960 x 576Multi Screen Display
1 / 4 / 7 / 8/ 9 / 13 / 16 / Sequence / PIP
-
Operating System Embedded
Linux
-
Recording Compression
H.264
Record Rate
NTSC : Up to 120 fps @ 1920 x 1080, 120 fps @ 960 x 480
PAL : Up to 100 fps @1920 x 1080, 100 fps @ 960 x 576Mode
NTSC : Manual, Schedule (Continuous/Event), Event (Pre/Post), Time Lapse (1~30 fps)
PAL : Manual, Schedule (Continuous/Event), Event (Pre/Post), Time Lapse (1~25 fps)Overwrite Modes
Stop / Continuous
Pre-alarm
Off / 5 sec
Post Alarm
Up to 6 hour (5,10, 20, 30 sec, 1, 3, 5, 10, 20 min, 1, 2, 3, 4, 5, 6 hour)
-
Search & Playback Search Mode
Date/Time, Event, Back up, Motion
Playback Function
Fast forward / backward, Slow forward / backward, Step forward / backward
-
Network Transmission Speed
NTSC: 4CIF 120 fps/ 2CIF 240 fps/ CIF 480 fps
PAL: 4CIF 100 fps/ 2CIF 200 fps/ CIF 400 fpsBandwidth
Up to 32Mbps
Bandwidth Control
Selectable
Stream
H.264 (4CIF / 2CIF / CIF Selectable)
Max. Remote Users
20 persons (Search up to 3 / Live unicast / Live multicast available)
Protocol Support
TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP, UPnP
Monitoring
SmartViewer, Webviewer, Mobile Viewer
-
Smart Phone Smart Phone
Supported / Web / App Viewer
-
Storage Internal HDD
2 TB SATA
USB (Back up)
2 USB ports
File Format (Back up)
BU (DVR player), EXE (Includes player)
-
Security Password Protection
1 Admin, 10 Group, 10 User per 1group
Data Authentication
Watermark
-
Monitor Interface VGA / HDMI
1 VGA (1280 x 720, 1280 x 1024, 1920 x 1080) / 1 HDMI (1280 x 720, 1280 x 1024, 1920 x 1080)
Simultaneous Output
VGA and HDMI
-
Audio Interface Inputs / Outputs
4CH line In / 1CH line out
Compression
G.711
-
Alarm Interface Remote Notification
Notification via e-mail
-
Connections Ethernet (LAN)
1 RJ-45 10/100Mbps Base-T
USB
USB 2.0, 2 ports (Front)
Application Support
Mouse, Remote control
Protocol Support (RS485)
Samsung-T/E, Pelco-D/P, Panasonic, Phillips, AD, VICON, GE
-
Electrical Input Volltage / Current
12V DC adapter, 4A, 100 ~ 250V AC, 50/60Hz
Power Consumption
Max. 40W (With 1x HDD + HD CAM 4 ea)
-
Environmental Conditions Operating Temperature (F)
0°C ~ +40°C (+32°F ~ +104°F)
Humidity
20% ~ 85%RH
-
Dimensions System Dimensions (WxHxD)
16.26" x 2.31" x 6.85"
-
Weight & Dimensions System Weight (with Hard Disks)
3.48 lbs
-
Languages Languages
English, Spanish, French, German, Italian, Polish, Portuguese, Russian, Turkish, Japanese, Czech, Swedish, Danish, Korean, Chinese, Netherland, Thai, Romanian, Serbian, Croatian, Hungarian, Greek, Finnish, Norwegian
-
Camera Input Voltage
12V DC
Power Consumption
SDC-9440BU: 4W
SDC-7340BCN: 3WImaging Device
SDC-9440BU: 1/2.9" 2M CMOS / 1920 x 1080
SDC-7340BCN: 1/3" 960H CMOSScanning System
SDC-9440BU: Progressive / Internal
SDC-7340BCN: InterlaceFrequency
SDC-7340BCN
NTSC: H: 15.734KHz / V: 59.94Hz
PAL: H: 15.625KHz / V: 50HzHorizontal Resolution
SDC-7340BCN
NTSC: 720TVL
PAL:700TVLMin. Illumination
0Lux (IR LED)
S/N Ratio (Y Signal)
SDC-7340BCN: 46dB
Shutter mode
Auto (Rolling shutter)
Gain Control
Auto
White Balance
Auto (1,800°K ~ 10,500°K)
Digital Noise Reduction
SDC-9440BU: SSNRIII (On)
SDC-7340BCN: AutoDay & Night
Mechanical: Auto (ICR)
IR Distance
SDC-9440BU: 30m (98ft)
SDC-7340BCN: 82ft (25m)Operating Temperature
-10°C ~ +50°C (+14°F ~ +122°F)
Humidity
85% RH
Igress Protection
IP66
Dimensions (WxHxD)
SDC-9440BU: 2.78" x 2.77" x 7.87"
SDC-7340BCN: 2.84" x 2.48" x 7.57"Weight
SDC-9440BU: 0.56 lb
SDC-7340BCN: 0.55 lb -
Lens Focal Length
3.8 mm
Max.Aperture Ratio
SDC-9440BU: F1.8
SDC-7340BCN: F2.0Angular Field of View
SDC-9440BU: H : 87.92˚ / V : 47.66˚ / D : 103.1˚
SDC-7340BCN: H: 60˚ / V: 48˚ / D: 72˚
![](http://image-us.samsung.com/SamsungUS/home/global-uvp/120318/MB-UVP-120318.jpg?$default-jpg$)
Financing that fits your life
* available on the SDC-9440BU camera
