The Wall All-in-One 146" (4K)
The Wall All-in-One 146" (4K)
- Images must be in BMP, PNG, GIF or JPEG format.
- File size must be 5 MB or less.
- Image must be at least 100 pixels tall.
- Image must be at least 100 pixels wide.
- It contains copyrighted media (and you don't hold the copyright)
- It contains media not related to the product
We may not publish your review if:
- It contains copyrighted media (an you don't hold the copyright)
- It contains media not related to the product
- • Seamless canvas for purer black levels with enhanced depth via Black Seal Technology
• Spectacular vibrancy for superior color purity to recreate scenes with Ultra Chroma Technology
• Reinvented installation process
• All-inclusive components built-in from control box to speaker
Get it by Dec. 9
Return Policy
VIP AdvantageMembers program
Upgrade to VIP AdvantageLearn more
- Samsung Care+2 year plan (without Theft & Loss)
- FREE Simple Installationor 50% OFF Complex Installations and TV Mounting
- Rewards Points: 6 pts / $1
- Plus more benefits..
$/yr
Get Stock Alerts
May we send you an alert when this product is available?
Let's keep in touch! Tick the box to receive promotional email and texts (which may be autodailed) from Samsung Electronics America to the number provided above.The Samsung Privacy Policy explains how we use your information. You do not have to consent to receive text messages to receive any product or services from us. Messaging and data rates may apply.
Learn how trade-in works
Finding the perfect fit can be a challenge. Now you can shop worry-free unlike ever before.
- Buy now by paying in full or with unbeatable Samsung Financing.
- Try out your purchase for up to 100 days, risk-free.
- Then, keep it or return it and get a full refund.
All-inclusive components
Black Seal Technology
Pre-assembled installation
Ultra Chroma Technology
Pure perfection on a deeper level
Black Seal Technology
A deep black background blankets the screen with accurate uniformity, creating a seamless canvas for purer black levels. The enhanced depth delivers unparalleled contrast and immaculate detail.
Superior color purity
Ultra Chroma Technology
Lavish, vibrant colors bring every scene to life for a superior immersive experience. Narrower wavelengths produce RGB colors two times purer and more accurate than conventional LEDs.¹
Installation, drastically simplified
The installation process for The Wall All-in-One is so efficient that it can be completed in as little as two hours, depending upon the size of your display. Now it’s easier than ever to have your home theater up and running in no time flat.²
-
Step 1
Mount the wall brackets.
-
Step 2
Dock the background plates.
-
Step 3
Hang the preset modules.
-
Step 4
Complete the install in 2 hours.
Auto configuration setup
Built-in Control Box
The control box for The Wall All-in-One is built into the display, which enables you to have the display up and running quickly, with no concerns about the configuration process.
Critical decisions without complexity
Simple Choice
Purchase The Wall All-in-One based on two simple factors: size and resolution. With streamlined pricing, you need not even consider complex elements traditionally associated with LED Displays, such as pixel pitch or configuration.
No extra peripherals needed
All-inclusive Components
The Wall All-in-One includes everything you need to begin enjoying the viewing experience—from the control box and wall brackets to speakers and deco bezels.
Colors mapped to perfection
20bit Processing
The Wall All-in-One offers 20bit processing to present precise color mapping with faultless accuracy. Deeper bit depth at low grayscale also delivers extraordinary contrast ratio and smooth, natural tones.
Continuous natural shading
Linear Grayscale
A precise linear grayscale showcases intricacies in every scene, delivering textures, volume, and continuous shadow details. The elevated continuity pulls you further into your content for unbroken immersion.
Instant AI optimization
Neural Quantum Processor 4K
Every second of content is instantly analyzed and optimized for perfect picture quality. The powerful AI processor delivers superior visuals in any size up to 4K resolution, enhancing contrast and removing noise.³
Dazzling dynamic range
MICRO HDR
Reimagine the limits of conventional screens with advanced picture refinement—HDR10/10+ and LED HDR. Ideal peak brightness and contrast are illuminated in every scene for precise imagery that is true-to-life, for a completely immersive viewing experience, right in your own living room.
Smooth, seamless motion
MICRO Motion
Every motion becomes sharper with superior clarity. The Wall All-in-One automatically converts standard 60Hz signals to 120Hz, eliminating motion judder in fast-paced action for smoother streams and a seamless viewing experience, every time.
-
Physical Parameter Pixel Pitch
0.84 ㎜
Pixel Configuration
1 red, 1 green, 1 blue
Diode Type
Flip-chip RGB LED
Configuration (LxH, per screen)
3840 x 2160 pixels
Dimensions (in, LxHxD, per screen)
127.1 x 71.6 x 1.9 in
Dimensions (inch, per screen)
145.7 x 1.9 inch
No. of Modules (WxH, per screen)
16 x 12
Weight (per screen)
168 lbs
Size
146" UHD
General Feature
IA Series
-
Optical Parameter Brightness (Peak / Max)
1600 nit / 500 nit
Contrast Ratio
24,000 : 1
HDR Compatibility
LED HDR / HDR10+ support / AI Picture
Viewing Angle - Horizontal
170°
Viewing Angle - Vertical
155°
Bit Depth
16 bit (Internal processing 20bit)
Color Temperature (Default)
6,500K ± 500K (Floating bin)
Color Temperature (Adjustable)
2,800K ~ 10,000K
Brightness (Peak/Max) (1)
1600 nit / 500 nit
-
Electrical Parameter Video Rate
50/60 Hz 100/120 (FRC) Hz
Input Power Range
100~240 VAC, 50/60 Hz
Power Consumption (Max)
1240 (W/Screen)
Power Consumption (Typical)
860 (W/Screen)
Heat Generation - Typ
3753 (BTU/Screen)
Refresh Rate
3,840 Hz
Heat Generation - Max
5800 (BTU/Screen)
-
Operation Conditions Working Temperature / Humidity
0℃~+40℃ / 10%~80%RH
Storage Temperature / Humidity
-20℃~+45℃ / 5%~95%RH
IP Rating
IP20
LED Lifetime
150,000 hours
-
Package Package Weight (per Cabinet)
301 kg
Box Dimension (mm, WxHxD)
2,000 × 2,162 × 1,000
-
Certification Eye-protection
TUV Low Blue Light
-
Service Service
Front
-
Features Operating System
Tizen 6.5
MagicINFO
Yes
Sensor
Temperature, Eco Sensor
Other
AI Picture, LED HDR, HDR10/10+, Dynamic Peaking
Other SW Features
Workspace (Microsoft365/VMWare/RDP), Auto Source Switching & Recovery, Dicom Simulation Mode, SmartView+(PC)
-
Connectivity / Sounds Controller
Built-in
Input (Video)
DP 1.2 (1), HDMI 2.0 (3), USB 2.0 (2)
Output
Audio (Stereo mini Jack) / eARC
WiFi / BT
O / O
External Control
RS232C(in), RJ45
Speaker
10W 2ch
-
Accessories Accessories
Décor Frame, Frame Kit, Buffer parts (18 Modules, 1 T-Con, 1 SMPS)
Remote Control
IR Remote Controller
-
Special Installation Other
Side by Side Installation with additional frame kit (up to 4 screens)
-
Certification and Compliance Safety
62368-1, 60950-1
EMC
Class A
