980 PRO NVMe™ M.2 SSD 250GB

Name: 980 PRO NVMe™ M.2 SSD 250GB
Brand: Samsung
SKU: MZ-V8P250BW
Rating: 5.0 (2 reviews)

Features
Gallery
Specs
Reviews
Support
Compare

Interface
Superfast Speeds
Intelligent Turbowrite
Temperature Control

Next-level SSD performance

Unleash the power of the Samsung PCIe 4.0 NVMe™ SSD 980 PRO for your next-level computing. Leveraging the PCIe 4.0 interface, the 980 PRO delivers double the data transfer rate of PCIe 3.0 while being backward compatible for PCIe 3.0 for added versatility.

* The NVM Express® design mark is a registered trademark of NVM Express, Inc.

Maximum speed

Powered by Samsung in-house controller for PCIe 4.0 SSD, the 980 PRO is optimised for speed. It delivers read speeds up to 7,000 MB/s, making it 2 times faster than PCIe 3.0 SSDs and 12.7 times faster than SATA SSDs. The 980 PRO achieves max speeds on PCIe 4.0 and may vary in other environments.

* Sequential and random write performance was measured with Intelligent TurboWrite technology being activated. Intelligent TurboWrite operatesonly within a specific data transfer size. Performance may vary depending on SSD’s firmware, system hardware & configuration and other factors. For detailed information, please contact your local service centre

A winning combination

Designed with hardcore gamers and tech-savvy users in mind, the 980 PRO offers high-performance bandwidth and throughput for heavy-duty applications in gaming, graphics, data analytics and more. It's fast at loading games, so you can play more and wait less.

Efficient M.2 SSD

The 980 PRO comes in a compact M.2 2280 form factor, which can be easily plugged into desktops and laptops for maximum board design flexibility. The drive is suitable for building high-performance computing systems due to its optimised power efficiency.

Reliable thermal control

High-performance SSDs usually require high-performance thermal control. To ensure stable performance, the 980 PRO uses nickel coating to help manage the controller's heat level and a heat spreader label to deliver effective thermal control of the NAND chip.

Smart thermal solution

Embedded with Samsung's cutting-edge thermal control algorithm, the 980 PRO manages heat on its own to deliver durable and reliable performance. To minimise performance fluctuations in the long haul, Samsung's Dynamic Thermal Guard technology maintains the 980 PRO's temperature at optimal levels.

Samsung Magician software

Unlock the full power of the 980 PRO with Samsung Magician's intuitive yet advanced optimisation tools. Monitor drive health, optimise performance, protect valuable data and receive important updates with Magician to ensure you're always getting the best performance out of your SSD.

World's No. 1 flash memory

Experience superior performance and reliability that you can only get from the world's number one brand for flash memory since 2003. All firmware and components, including Samsung's world-renowned DRAM and NAND, are produced in-house, allowing end-to-end integration for quality you can trust.

*Source: 2003-Q4.2021 OMDIA data: NAND suppliers' revenue market share.

Specifications

Interface PCIe Gen 4.0 x4, NVMe 1.3c
Storage Memory Samsung V-NAND 3-bit MLC
Controller Samsung Elpis Controller

General Feature

Application Client PCs
Capacity 250GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor M.2 (2280)
Interface PCIe Gen 4.0 x4, NVMe 1.3c
Dimension (WxHxD) 80.15 x 22.15 x 2.38 (mm)
Weight Max 9.0 g Weight
Storage Memory Samsung V-NAND 3-bit MLC
Controller Samsung Elpis Controller
Cache Memory Samsung 512MB Low Power DDR4 SDRAM

Special Feature

TRIM Support Supported
S.M.A.R.T Support Supported
GC (Garbage Collection) Auto Garbage Collection Algorithm
Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support Not supported
Device Sleep Mode Support Yes

Performance

Sequential Read Up to 6,400 MB/s * Performance may vary based on system hardware & configuration
Sequential Write Up to 2,700 MB/s * Performance may vary based on system hardware & configuration
Random Read (4 KB, QD32) Up to 500,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32) Up to 600,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4 KB, QD1) Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4 KB, QD1) Up to 60,000 IOPS * Performance may vary based on system hardware & configuration

Environment

Average Power Consumption (system level) *Average: 5 W *Maximum: 7 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle) Max. 35 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage 3.3 V ± 5 % Allowable voltage
Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
Operating Temperature 0 - 70 ℃ Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)

Accessories

Installation Kit Not Available

Software

Management SW Magician Software for SSD management

Warranty

5-Year Limited Warranty or 150 TBW Limited Warranty
