970 PRO NVMe™ M.2 SSD 1TB

Name: 970 PRO NVMe™ M.2 SSD 1TB
Brand: Samsung
SKU: MZ-V7P1T0BW
Rating: 4.8 (29 reviews)

Features
Gallery
Specs
Reviews
Support
Compare

The SSD that goes beyond

Experience the best. For intensive workloads on PCs and workstations, the 970 PRO gives utmost performance enabled by Samsung†s NVMe™ SSD leadership. The latest V-NAND technology and new Phoenix controller in a compact M.2 (2280) form factor surpass the demands of tech enthusiasts and professionals.

* The NVM Express® design mark is a registered trademark of NVM Express, Inc.

Fearless Performance

Performance that puts you in command. The 970 PRO combines the next-gen PCIe Gen 3x4 NVMe interface with the latest V-NAND technology and a newly enhanced Phoenix controller to achieve fearless read/write speeds of up to 3,500/2,700 MB/s*, approximately 30 percent faster than the previous generation.

* Sequential and random performance measurements are based on IOmeter 1.1.0. Performance may vary based on the SSD†s firmware version, system hardware and configuration.* Test system configuration: Intel® Core i7-7700K CPU@4.2GHz, DDR4 2400MHz 32GB, OS-Window 10 Built 10240, Chipset-ASUS PRIME Z270-A

Exceptional Endurance

Get the ultimate sustainable performance. The 970 PRO delivers up to 1,200 TBW* with a 5-year limited warranty, achieving 50 percent greater endurance than the previous generation, all powered by the latest V-NAND technology.

* TBW: Terabytes Written* Warrantied TBW for 970 PRO: 600 TBW for 512GB model, 1,200 TBW for 1TB model.* 5-years or TBW, whichever comes first. For more information on the warranty, please find the enclosed warranty statement in the package.

Unparalleled Reliability

Achieve a new level of drive confidence. Samsung’s advanced nickel-coated controller and heat spreader on the 970 PRO enable superior heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to minimise performance drops.

Samsung Magician

Advanced drive management made simple. The Samsung Magician software will help you keep an eye on your drive. A suite of user-friendly tools helps keep your drive up to date, monitor drive health and speed, and even boost performance.

Specifications

Application Client PCs
Interface PCIe Gen 3.0 x4, NVMe 1.3
Dimension (WxHxD) 80.15 x 22.15 x 2.38 (mm)
Weight Max 8.0 g Weight
Performance Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write Up to 2,700 MB/s * Performance may vary based on system hardware & configuration

General Feature

Application Client PCs
Capacity 1,024GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor M.2 (2280)
Interface PCIe Gen 3.0 x4, NVMe 1.3
Dimension (WxHxD) 80.15 x 22.15 x 2.38 (mm)
Weight Max 8.0 g Weight
Storage Memory Samsung V-NAND 2-bit MLC
Controller Samsung Phoenix Controller
Cache Memory Samsung 1GB Low Power DDR4 SDRAM

Special Feature

TRIM Support Supported
S.M.A.R.T Support Supported
GC (Garbage Collection) Auto Garbage Collection Algorithm
Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support Not supported
Device Sleep Mode Support Yes

Performance

Sequential Read Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write Up to 2,700 MB/s * Performance may vary based on system hardware & configuration
Random Read (4 KB, QD32) Up to 500,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32) Up to 500,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4 KB, QD1) Up to 15,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4 KB, QD1) Up to 55,000 IOPS * Performance may vary based on system hardware & configuration

Environment

Average Power Consumption (system level) * Average: 5.7 W * Maximum: 8.5 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle) Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage 3.3 V ± 5 % Allowable voltage
Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
Operating Temperature 0 - 70 ℃ Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)

Accessories

Installation Kit Not Available

Software

Management SW Magician Software for SSD management

Warranty

5-Year Limited Warranty or 1,200 TBW Limited Warranty
