Expand commercial space with compact display
Get the most out of every space with Samsung QB24C small digital signage. The compact display provides sharp messaging with its Full HD resolution. Its enhanced internal solutions and intuitive home screen UX make it easy to use, also ensuring reliable performance for any business use.
Hold sizable opportunities in small spaces
Compact Design
The compact design of the QB24C allows for efficient space utilization, even in compact locations. A sleek rear design makes the display optimal for wall mounting while the connectivity, content play and device controls are easy to operate.
Connect with convenience
Home UI
QB24C boasts greater usability with an upgraded home screen UI. Popular categories like Features, Sources and Settings are displayed on the same screen for convenient availability. The Favorites folder grants users quick, easy access to frequently used features in a single click.
Convenient, clean display control
Center IR
With center IR, each display receives IR signals directly to the panel, allowing easy and convenient remote control. When mounted, the display doesn't require an IR receiver cable extension. Built-in Wi-Fi allows wireless remote management for both content and display.
Safe operation, reliable performance
IP5X / EMC Class B
QB24C is electromagnetic compatibility (EMC) class B compliant, meeting strict safety and reliability standards for operation. Additionally, the display's IP5x rating underscores its robust durability even in dusty environments.
Change the way to manage your display
Samsung VXT
Samsung VXT is a cloud-based solution that brings together content management and remote device management capabilities, allowing users to remotely manage hardware settings and troubleshoot issues from afar, while effortlessly creating and deploying content without the need for training.
* Samsung VXT must be purchased separately.
Specifications
Full specifications
Display
- Diagonal Size 23.8"
- Panel Type ADS
- Resolution 1,920 x 1,080
- Pixel Pitch (HxV) 0.2745 x 0.2745 mm
- Brightness (Typ) 250 nit
- Contrast Ratio 1,000:1
- Viewing Angle (Horizontal/Vertical) 178/178
- Response Time 14ms
- Colour Gamut 72(NTSC)
- Glass Haze 25 %
- H-Scanning Frequency 56~84.5KHz
- Maximum Pixel Frequency 148.5MHz
- V-Scanning Frequency 48~75Hz
- Contrast Ratio (Dynamic) Mega
- Operation Time Support 16/7
Connectivity
- HDMI In 1
- DP In No
- Version of HDMI 1.4
- Version of DP No
- Version of HDCP 2.2
- USB 1
- IR In Yes
- Audio In No
- Audio Out Stereo Mini Jack
- RS232 In Yes
- RJ45 In Yes
- WiFi Yes
- Bluetooth Yes
Power
- Power Supply AC100-240V 50/60Hz
- Power Consumption (On Mode) 38.5 W
- Power Consumption (Sleep Mode) 0.5 W
Dimension
- Set Dimension (WxHxD) 547.9 x 334.4 x 31.8 mm
- Package Dimension (WxHxD) 620 x 419 x 122 mm
Weight
- Set Weight 3.0 kg
- Package Weight 4.1 kg
Operation Conditions
- Temperature 0 °C~ 40 °C
- Humidity 10 ~ 80%, non-condensing
Mechanical Specification
- VESA Mount 100 x 100 mm
- Bezel Width UD : 17.9 / LR : 9.4
- Frame Material Non-Glossy
Optional Feature
- Mount No
- Stand No
SoC
- OS Version Tizen 7.0
- Flash Memory Size 8GB
Certification and Compliance
- EMC Class B
- Safety 60950-1, 62368-1
Support
Find answers to the questions you have about our products
-
User Manual
- ver 2409270
- 69.35 MB
- 01.10.2024
ENGLISH, BULGARIAN, CROATIAN, CZECH, DANISH, DUTCH, ESTONIAN, FINNISH, FRENCH(FRANCE), GERMAN, GREEK, HUNGARIAN, ITALIAN, LATVIAN, LITHUANIAN, NORWEGIAN, POLISH, PORTUGUESE(European), ROMANIAN, SERBIAN, SLOVAK, SLOVENIAN, SPANISH, SWEDISH, TURKISH -
Quick Setup Guide
- ver 2308180
- 1.12 MB
- 29.11.2023
ENGLISH, BULGARIAN, CROATIAN, CZECH, DANISH, DUTCH, ESTONIAN, FINNISH, FRENCH(FRANCE), GERMAN, GREEK, HUNGARIAN, ITALIAN, LATVIAN, LITHUANIAN, NORWEGIAN, POLISH, PORTUGUESE(European), ROMANIAN, SERBIAN, SLOVAK, SLOVENIAN, SPANISH, SWEDISH, TURKISH
