55" Razor Narrow Bezel Video Wall VMB-R

55" Razor Narrow Bezel Video Wall VMB-R

LH55VMBRBGBXXS

  • Nearly invisible 0.44mm bezel
  • Vibrant images in any light
  • Non-glare panel

Choose your Colour

Choose your size

55" Razor Narrow Bezel Video Wall VMB-R

Black 55"

Seamless video walls with razor-thin bezels

With an exceptionally narrow bezel measuring at just 0.44 mm, it is also equipped with Samsung’s advanced picture enhancement technology along with wide viewing angles. The VMB-R delivers an impactful and seamless experience while the modern, slim design allows the display to blend into any business environment.

Seamless video walls with razor-thin bezels Seamless video walls with razor-thin bezels

Nearly invisible 0.44 mm bezel

An exceptionally thin 0.44mm even bezel enables content to be delivered as one seamless image. Additionally, the display helps to eliminate any potential image distortion and provides a more immersive viewing experience.

Nearly invisible 0.44 mm bezel Nearly invisible 0.44 mm bezel

View content from any angle

The display’s wide viewing angles mean content is easily visible even if viewers aren’t standing directly in front of the display. Audiences can get clear and accurate information regardless of video wall layout or location.

View content from any angle View content from any angle

Image enhancement technology

Samsung’s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, colour saturation and contrast are improved by adjusting the gamma curve. With Black Equalizer mode, details are easier to see.

Image enhancement technology Image enhancement technology

Modern, slim design

VMB-R displays feature an elevated design aesthetic with an ultra-slim depth of less than 70 mm. This saves spaces and creates a clean, modern look for retail or other public spaces.

Modern, slim design Modern, slim design

Vibrant images 24/7

Experience brilliant image presentation with an impressive 500 nit brightness allowing businesses to deliver clear information 24/7. The display’s non-glare panels provide better visibility regardless of ambient light, ensuring critical information is always visible.

Vibrant images 24/7 Vibrant images 24/7

Convenient mobile calibration

Samsung’s Colour Expert Pro Mobile* solution provides a quick and easy video wall calibration through a mobile camera. With the solution’s intuitive UI, even non-expert users can adjust up to 5x5 video wall’s white balance simultaneously without the need for additional equipment.

Convenient mobile calibration Convenient mobile calibration

* Samsung Colour Export Pro Mobile is only available on certain smartphone models.

Comprehensive calibration

Samsung’s multi-step factory calibration process tunes video walls to uniform brightness and colour throughout multiple displays. In addition to rigorous factory calibration, users can also manage brightness and colour uniformity with Samsung's Colour Expert Pro, a powerful free software program.

Comprehensive calibration Comprehensive calibration

Advanced UHD presentation

Samsung video walls provide an impressive UHD viewing experience with minimal effort. With daisy chain design utilising DisplayPort 1.2 and HDMI ports, the VMB-R display can project UHD content across multiple screens — up to 5 x 5, without requiring an external graphic card or UHD splitters.

Advanced UHD presentation Advanced UHD presentation

Industry standard certified

The VMB-R series is EMC class A compliant, meeting strict standards of electromagnetic wave emission, while IP5x certification protects the display against dust and other conditions. The display packaging also passed a rigorous 4-step, ISTA-certified test to minimise possible damage during delivery.

Industry standard certified Industry standard certified

1 EMC: Electromagnetic compatibility. 2 IP5x validation ensures satisfactory operation even with a certain level of dust inside the product. Exposure to particular types of dust, such as metal dust, may affect product operation. 3 ISTA: International Safe Transit Association.

Intuitive all-in-one operations

The UHD Signage Player Box* combines information processing and content management tools into a single platform, for added operational simplicity. Weighing just 0.6 kg, while embedded with MagicINFO S Player 6 and SSSP 6, the compact design of the box makes it an ideal solution.

Intuitive all-in-one operations Intuitive all-in-one operations

* The Signage Player Box is sold separately.

Specifications

Display

  • Diagonal Size 55"
  • Panel Type IPS
  • Resolution 1,920 x 1,080
  • Pixel Pitch (HxV) 0.63x0.63
  • Brightness (Typ) 500nit
  • Contrast Ratio 1,100:1
  • Viewing Angle (H/V) 178/178
  • Response Time 8ms
  • Colour Gamut 72 %
  • Glass Haze 28 %
  • H-Scanning Frequency 57.3kHz ~ 70kHz
  • Maximum Pixel Frequency 78MHz
  • V-Scanning Frequency 47Hz ~ 63Hz
  • Contrast Ratio (Dynamic) 500,000:1
  • Operation Time Support 24/7

Connectivity

  • HDMI In 2
  • DP In 1
  • DVI In Yes
  • Version of HDMI 2
  • Version of DP 1.2
  • Version of HDCP 2.2
  • USB 1
  • IR In Yes
  • Audio In Yes
  • Audio Out Stereo Mini Jack
  • Video Out Yes
  • Power Out No
  • RS232 In Yes
  • RS232 Out Stereo Mini Jack
  • RJ45 In Yes
  • WiFi No

Power

  • Power Supply AC100-240V 50/60Hz
  • Power Consumption (On Mode) 270 W
  • Power Consumption (Sleep Mode) 0.5 W

Dimension

  • Set Dimension (WxHxD) 1211.0 x 681.7 x 69.9 mm
  • Package Dimension (WxHxD) 1414.0 x 844.0 x 257.0 mm

Weight

  • Set Weight 16.8 kg
  • Package Weight 25.1 kg

Operation Conditions

  • Temperature 0℃~ 40℃
  • Humidity 10 ~ 90%

Mechanical Specification

  • VESA Mount 600 x 400 mm
  • Bezel Width 0.44 (even)
  • Frame Material Glossy

Optional Feature

  • Mount Yes
  • Stand No

Certification and Compliance

  • EMC FCC (USA) Part 15, Subpart B Class A CE (Europe) : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 VCCI (Japan) : VCCI V-3 /2010.04 Class A KCC/EK (Korea) : Tuner : KN13 / KN20 Tunerless : KN22 / KN24 BSMI (Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital) C-Tick (Australia) : AS/NZS CISPR22:2009 CCC(China) :GB9254-2008 GB17625.1-2012 GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97 EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003
  • Safety CB (Europe) : IEC60950-1/EN60950-1CCC (China) : GB4943.1-2011PSB (Singapore ) : PSB+IEC60950-1NOM (Mexico ) : Tunerless : NOM-019-SCFI-1998IRAM (Argentina ) : IRAM+IEC60950-1SASO (Saudi Arabia ) : SASO+IEC60950-1BIS(India) : IEC60950-1 / IS13252KC(Korea) : K 60950-1EAC(Russia) : EAC+IEC60950-1INMETRO(Brazil) : INMETRO+IEC60950-1BSMI(Taiwan) : BSMI+IEC60950-1RCM(Australia) : IEC60950-1/AS/NZS 60950-1UL(USA) : cUL60950-1 CSA (Canada) : cULTUV (Germany) : CENEMKO (Norway) : CE
