Features
BLDC (Twin Rotary) Compressor
A key contributor to the FJM’s efficiency is its BLDC (Twin Rotary) Compressor, which is featured on all outdoor models. Its twin eccentric cams and two balance weights result in extremely low levels of vibration, contributing to a much quieter all-round performance. Attention to the quality of moving parts such as robust bearings, as well as premium matching rollers and vanes produce a high degree of stability and durability.
Reduced Vibration and Noise
All new FMJ outdoor models incorporate the TBR Sine-Wave Compressor in addition to the twin BLDC compressor. This serves to reduce torque variation by 70 per cent and vibration by 80 per cent compared to a regular single compressor. As a result, stress on the motor is kept to a minimum, and the lifespan of the air conditioning unit is extended. A further benefit is a significant reduction in noise, leading to a more comfortable and productive working environment.
Specifications
-
Power Supply (Outdoor Unit) [Φ, #, V, Hz]
1,2,220~240,50/60
-
EER (Nominal Cooling) [W/W]
4.08
-
Net Dimensions (WxHxD) (mm)
880 x 638 x 310 mm
-
Type
FREE JOINT MULTI
-
Outdoor Unit
AJ058TXJ3KC/EA
-
1,2,220~240,50/60
-
Mode
COOLING ONLY
-
Cooling [kW]
5.8 kW
-
Cooling [Btu/h]
19,700 Btu/h
-
Cooling 1)
1.42 kW
-
Cooling
6.5 A
-
MCA [A]
15.2 A
-
MFA [A]
17.5 A
-
EER (Nominal Cooling) [W/W]
4.08
-
Type
Twin BLDC Rotary
-
Output(kW)
5.92 x 1 kW
-
Model Name
UG4T200FUAE4
-
Oil (Type)
POE
-
Oil (Initial Charge) [cc]
650 cc
-
Type
Propeller Fan
-
Motor (Output) [W]
125 W
-
Air Flow Rate (High / Mid / Low) [CMM]
38.0 CMM
-
Air Flow Rate(High/Mid/Low)[L/S]
633 L/S
-
Liquid Pipe (Ø,mm x EA)
6.35 x 3
-
Liquid Pipe (Ø,inch x EA)
1/4 x 3
-
Gas Pipe (Ø,mm x EA)
9.52 x 2 + 12.70
-
Gas Pipe (Ø,inch x EA)
3/8 x 2 + 1/2
-
Installation Max. Length [m]
50 m
-
Installation Max. Height [m]
15 m
-
Power Source Wire
2.5 ~ 2.5
-
Transmission Cable
0.75 ~ 1.5
-
Type
R410A
-
Factory Charging (kg)
1.9 kg
-
Factory Charging (tCO2e)
4.59 tCO2e
-
Sound Pressure
46 dBA
-
Panel Net Weight (kg)
46.5 kg
-
Shipping Weight (kg)
49.5 kg
-
Net Dimensions (WxHxD) (mm)
880 x 638 x 310 mm
-
Shipping Dimensions (WxHxD) (mm)
1,023 x 742 x 413 mm
-
Cooling (℃)
10.0 ~ 46.0 ℃
