9100 PRO NVMe™ M.2 SSD 4TB

MZ-VAP4T0BW

0 ( 0 )

Choose your Colour

Colour : Black

Choose your Memory

9100 PRO NVMe™ M.2 SSD 4TB
Black 4 TB

From $83.25/mo* with 0% interest with Q Card for 12 months or $999.01

Add to cart Where to buy

Features

Performance ready for a new era

Top 3 features

With the 9100 PRO it says "up to 2x faster" and "PCIe® 5.0".

PCIe® 5.0 Performance

Max 14,800/13,400 MB/s sequential speeds, two times faster than 990 PRO.

Various game screens are shown centered around the 9100 PRO, and it says "8TB".

Expanded Experience

Supermassive capacity with exceptional compatibility.1

The detailed components that make up the 9100 PRO are visible. There are two components that say "SAMSUNG V-NAND" and one component each that says "SAMSUNG DRAM" and "SAMSUNG Controller." Around it, an arrow indicating the direction in which heat is emitted is visible.

Innovative Power & Thermal Control

Up to 49% enhanced power efficiency with advanced thermal control.

Breakthrough PCIe® 5.0 performance

Push PCIe® 5.0 performance to the max. 9100 PRO achieves lightning-fast sequential read/write speeds up to 14,800/13,400 MB/s, with sequential read speeds up to two times faster than 990 PRO. Leave Gen4 limits behind with random read/write speeds up to 2,200K/2,600K IOPS, only possible by Gen5.2

With the 9100 PRO, it says "up to 2x faster", "PCIe® 5.0". Below that, it says "Sequential Read up to 14,800 MB/s", "Sequential Write up to 13,400 MB/s" with icons indicating Sequential speed, and "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" with icons indicating Random speed. With the 9100 PRO, it says "up to 2x faster", "PCIe® 5.0". Below that, it says "Sequential Read up to 14,800 MB/s", "Sequential Write up to 13,400 MB/s" with icons indicating Sequential speed, and "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" with icons indicating Random speed.

Every task, powerfully parallel

Speed past productivity limits. Exhilarating random read/write speeds enable ultra-fast parallel processing for countless fragmented data, at up to 2,200K/2,600K IOPS. Experience superior output and instant loads for huge games, high-performance tasks, and even AI applications.

Several puzzle pieces are coming together. It says "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" along with an icon indicating Random speed. Several puzzle pieces are coming together. It says "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" along with an icon indicating Random speed.

Create with AI in an instant

Intelligence redefines performance. Defy your limits in work and play with an on-board AI PC and AI content generation, fuelled by 9100 PRO’s exhilarating random read/write speeds up to 2,200K/2,600K IOPS. Swift loads, smooth gameplay, seamless performance.3

A person is using an AI application on a laptop. It has the words "Random Read up to 2,200K IOPS" and "Random Write up to 2,600K IOPS" written on it, along with an icon indicating random speed. A person is using an AI application on a laptop. It has the words "Random Read up to 2,200K IOPS" and "Random Write up to 2,600K IOPS" written on it, along with an icon indicating random speed.

Exceptional everywhere

Elevate your competitive edge. Breeze through video editing, 3D art, and even long streaming sessions with the latest PCIe® 5.0 interfaces. Experience cutting-edge performance anytime, anywhere, on any device, and choose the storage you need with expansive capacity up to 8TB. 4

Several cases of using desktop PC, laptop. Below, there are icons written by 1TB, 2TB, 4TB, and 8TB. Several cases of using desktop PC, laptop. Below, there are icons written by 1TB, 2TB, 4TB, and 8TB.

Extraordinary thermal efficiency

Peak performance, uninterrupted. The advanced 5nm controller power architecture enhances power efficiency up to 49% over 990 PRO. Exceptional thermal control ensures nothing disrupts your flow, so you can keep the most demanding programs running with the max possible power of PCIe® 5.0.5

The detailed components that make up the 9100 PRO are visible. There are two components that say "SAMSUNG V-NAND" and one each that says "SAMSUNG DRAM" and "SAMSUNG Controller." Around it, an arrow indicating the direction in which heat is emitted is visible, and "Nickel coated controller" and "Heat spreader label" are written. On one side again, "Thermal Control" is written with the icon, which means temperature control. The detailed components that make up the 9100 PRO are visible. There are two components that say "SAMSUNG V-NAND" and one each that says "SAMSUNG DRAM" and "SAMSUNG Controller." Around it, an arrow indicating the direction in which heat is emitted is visible, and "Nickel coated controller" and "Heat spreader label" are written. On one side again, "Thermal Control" is written with the icon, which means temperature control.

Samsung Magician software

Make your SSD work like magic. Samsung Magician software's optimisation tools ensure the best SSD performance. It's a safe and easy way to migrate all your data for a Samsung SSD upgrade. Protect valuable data, monitor drive health, and get the latest firmware updates. 6

Samsung magician software is running on the PC screen.Below that, the three core functions "Data Migration", "Integrative drive Health check", and "Firmware Update" are indicated in text and icons. Samsung magician software is running on the PC screen.Below that, the three core functions "Data Migration", "Integrative drive Health check", and "Firmware Update" are indicated in text and icons.

Bringing innovations to life

For decades, Samsung’s NAND flash memory has powered groundbreaking technologies that have changed every part of our daily lives. This NAND flash technology also powers our consumer SSDs, making room for the next big push of innovation.

Samsung's memory products are installed on the motherboard. Samsung's memory products are installed on the motherboard.

Specifications

  • Interface

    PCIe® 5.0 x4, NVMe™ 2.0

  • Sequential Read

    Up to 14,800 MB/s * Performance may vary based on system hardware & configuration

  • Sequential Write

    Up to 13,400 MB/s * Performance may vary based on system hardware & configuration

  • Warranty

    5-year Limited Warranty or 2,400TBW Limited Warranty

  • Application

    Client PCs, Game Consoles

  • Weight

    Max 9.0g Weight

  • Dimension (WxHxD)

    Max 80.15 x Max 22.15 x Max 2.38 mm

  • Application

    Client PCs, Game Consoles

  • Capacity

    4,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

  • Form Factor

    M.2 (2280)

  • Interface

    PCIe® 5.0 x4, NVMe™ 2.0

  • Dimension (WxHxD)

    Max 80.15 x Max 22.15 x Max 2.38 mm

  • Weight

    Max 9.0g Weight

  • Storage Memory

    Samsung V-NAND TLC

  • Controller

    Samsung in-house Controller

  • Cache Memory

    Samsung 4GB Low Power DDR4X SDRAM

  • TRIM Support

    Supported

  • S.M.A.R.T Support

    Supported

  • GC (Garbage Collection)

    Auto Garbage Collection Algorithm

  • Encryption Support

    AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)

  • WWN Support

    Not supported

  • Device Sleep Mode Support

    Yes

  • Sequential Read

    Up to 14,800 MB/s * Performance may vary based on system hardware & configuration

  • Sequential Write

    Up to 13,400 MB/s * Performance may vary based on system hardware & configuration

  • Random Read

    Up to 2,200,000 IOPS * Performance may vary based on system hardware & configuration

  • Random Write

    Up to 2,600,000 IOPS * Performance may vary based on system hardware & configuration

  • Average Power Consumption (system level)

    Average: Read 9.0 W / Write 8.2 W* Actual power consumption may vary depending on system hardware & configuration

  • Power consumption (Idle)

    Typical 6.5 mW * Actual power consumption may vary depending on system hardware & configuration

  • Power Consumption (Device Sleep)

    Typical 5.7 mW * Actual power consumption may vary depending on system hardware & configuration

  • Allowable Voltage

    3.3 V ± 5 % Allowable voltage

  • Reliability (MTBF)

    1.5 Million Hours Reliability (MTBF)

  • Operating Temperature

    0 - 70 ℃ Operating Temperature

  • Shock

    1,500 G & 0.5 ms (Half sine)

  • Installation Kit

    Not Available

  • Management SW

    Magician Software for SSD management

  • 5-year Limited Warranty or 2,400TBW Limited Warranty
