Highlights
Compact & Lightweight
Auto ESP Adjustment
3-way access
Smart Inverter System
Features
Install anywhere and maintain easily
Small & lightweight
Fit your air conditioner into even the smallest spaces. A lightweight and compact Slim Fit design is 30% smaller and 42% lighter than conventional air conditioners*. It makes it much easier to handle and set up, and means it can be installed almost anywhere in a building with little difficulty.
* Based on internal testing compared to competing air conditioners.
Simple set up, automatically even cooling
Auto ESP Adjustment
Enjoy maximum comfort and efficiency with minimum effort. The Auto ESP Adjustment automatically optimizes the air volume and pressure and minimizes noise, ensuring consistent cooling and heating in any situation. The external static pressure (ESP) can also be adjusted using a remote control.
Simple to service in various locations
3-way Service Access
Install your ducted air conditioner in various locations, but still enjoy easy access for servicing. It can be accessed from three directions–top, side and bottom–using an easy to remove Slide Fit cover. So it’s simple to maintain wherever it’s installed in, which saves you time and money.
World-class energy efficiency & savings
Smart Inverter System
Save money without sacrificing performance with its outstanding energy efficiency, earning it a Top-level Energy Efficiency Ratio. A large Sirocco Fan with aerodynamic blades and a DC Fan Motor expels more air, with less noise*. And the Twin Rotary BLDC Compressor is quieter and more reliable.
* Based on internal testing compared to conventional air conditioners. Results may vary depending on environmental factors and individual use.
Specifications
-
Capacity
3.6
-
Cooling [Btu/h]
12,300
-
Model Name
AM036ANMPKH/EU
-
Features
Duct S
-
Type
Duct S
-
Indoor Unit
AM036ANMPKH/EU
-
1,2,220~240V,50/60
-
Mode
HP / HR
-
Cooling [kW]
3.6
-
Cooling [Btu/h]
12,300
-
Heating [kW]
4.0
-
Heating [Btu/h]
13,600
-
Cooling 1) [W]
45.0
-
Heating 2) [W]
45.0
-
Cooling
0.4 A
-
Heating
0.4 A
-
Type
Sirocco Fan
-
Motor (Output) [W]
153
-
Number of Unit (EA)
1
-
Air Flow Rate (High / Mid / Low) [CMM]
12/9.5/7.5
-
External Static Pressure (Min / Std / Max) [mmAq]
0/2.5/15
-
External Static Pressure (Min / Std / Max) [Pa]
0.00/24.52/147.10
-
Liquid Pipe (Φ, mm)
6.35
-
Liquid Pipe (Φ, inch)
1/4
-
Gas Pipe (Φ, mm)
12.7
-
Gas Pipe (Φ, inch)
1/2
-
Drain Pipe (Φ,mm)
VP25 (OD 25,ID 20)
-
Type
R410A
-
Control Method
EEV INCLUDED
-
Sound Power Level
53 dBA
-
Sound Pressure (High / Mid / Low) [dB(A)]
30/27/24
-
Panel Net Weight (kg)
27.9
-
Shipping Weight (kg)
32.0
-
Net Dimensions (WxHxD) (mm)
850 x 250 x 700
-
Shipping Dimensions (WxHxD) (mm)
1064 x 320 x 784
-
Drain Pump
Built In
-
Power Source Wire
1.5 ~ 2.5
-
Transmission Cable
0.75 ~ 1.5
