Attract customers with optimized 16/7 performance
Attract customers with optimized 16/7 performance
Engage customers and vividly display business messaging with affordable Samsung SMART Signage DCE Series, featuring high picture quality with 350 nit brightness (32" - 330nit) and reliable 16/7 usage. With a slim, sleek design for extended indoor use in retail stores, Quick Service Restaurants (QSRs), small businesses and corporate conference rooms and offices, DCE Series displays stunningly present a range of immersive and timely information with captivating picture quality
Content Auto Play in USB memory or internal memory
Content Auto Play in USB memory or internal memory
MagicInfo Lite Player uses a sophisticated technology to play a huge range of content including video, images, photos on demand, or from a pre-set schedule. Customers can easily play files from, or transfer between, the large internal memory and external USB devices plugged into the in-built port. The MagicInfoSlide folder on the USB memory has content that is listed in alphabetical order which is easier and convenient to use as it does not require separate schedules.
Control Displays in multiple locations easily and instantly
Control Displays in multiple locations easily and instantly
MagicInfo Lite solution comes with the embedded media player, and is able to extend the remote content management to be over network through the MagicInfo server. Media contents of the USB memory stick plugged in to the DCE Series displays can be scheduled to play from a remote PC.
The connection to MagicInfo server also allows remote monitoring and management of the DCE Series displays. Device information, content playback schedules, network data monitoring, time scheduling, alarms and various controls can all be done remotely, without the need to be in front of the displays.
Easily manage digital signage with a versatile connectivity
Easily manage digital signage with a versatile connectivity
Connect the SMART Signage DCE Series to other digital signage easily with interfaces based on your specific needs. The displays provide not only the essential connections businesses use most frequently, but also support a wide range of source device types. Interfaces include HDMI, DVI, D-sub, Component and Composite input as well as RS-232C and RJ45 for extensive connectivity.
In addition, DCE series has a slot to attach a SBB player, which can transform the signage into all-inclusive digital signage solutions.
Specifications
Specifications Detail
Display
- Diagonal Size 55"
- Panel Type 60Hz D-LED BLU
- Resolution 1920 x 1080 (16:9)
- Pixel Pitch (HxV, mm) 0.21 x 0.63
- Active Display Size (HxV, mm) 1209.6 x 680.4
- Contrast Ratio 5,000:1
- Viewing Angle (H/V) 178/178
- Response Time 6 ms
- Display Color 16.7M
- Color Gamut 72 %
- H-Scanning Frequency 30 ~ 81kHz
- Maximum Pixel Frequency 148.5MHz
- V-Scanning Frequency 48 ~ 75Hz
- Brightness 350
- Contrast Ratio (Dynamic) MEGA
Connectivity
- HDMI In 2
- DVI In 1
- USB 1
- Component In 1 (Composite Common)
- Composite In 1
- RGB In D-Sub
- IR In Yes
- Audio In Stereo Mini Jack, RGB/DVI/HDMI/CVBS/Component Audio(Common)
- Audio Out Stereo Mini Jack
- RS232 In Yes
- RJ45 In Yes
Design
- Stand Type Foot Stand (Optional)
Power
- Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
- Power Consumption (Off Mode, W) 0.00
- Power Consumption (On Mode, W) Max:176W / Typical:(W/W)115, (US)55, (KR)133W / BTU(Max):600.16W
- Power Consumption (Sleep Mode, W) less than 0.5
Dimension
- Set Dimension (WxHxD, mm) 1230.6 x 706.9 x 49.9
- Package Dimension (WxHxD, mm) 1348 x 810 x 148
Weight
- Set Weight 14.7
- Package Weight 19.2
Operation Conditions
- Temperature 0~40 ℃
- Humidity 10~80 %
Mechanical Specification
- VESA Mount (mm) 400 x 400
- Bezel Width (mm) 10.5 (Top/Side), 15.0 (Bottom)
- Media Player Option Type Embbeded, SBB (Attachable)
General Feature
- Special Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W x 2)
- Speaker 10W x 2
Optional Feature
- Mount WMN4270SD, WMN450MD, WMN4675MD
- Specialty CML450D (Ceiling Mount)
- Stand STN-L4655E
Internal Player (MagicInfo)
- Special Auto Source Switching & Recovery, RS232C/RJ45 MDC, Plug and Play (DDC2B), Built In MagicInfo Lite, Firmware Update by Network
- MagicInfo Support Yes
Eco
- Energy Efficiency B
Accessory
- Included Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries, RS232C(IN) Adapter
Certification and Compliance
- EMC FCC (USA) Part 15, Subpart B Class A, CE (Europe) : EN55022:2006+A1:2007, EN55024:1998+A1:2001+A2:2003, VCCI (Japan) : VCCI V-3 /2010.04 Class A, KCC/EK (Korea) : Tunerless : KN22 / KN24, BSMI (Chinese Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) CNS14972 (Digital), C-Tick (Australia) : AS/NZS CISPR22:2009, CCC(China) : GB9254-2008, GB17625.1-2012, GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97, EN55022:2006+A1:2007, EN55024 : 1998+A1:2001+A2:2003
- Safety CB (Europe) : IEC60950-1/EN60950-1, CCC (China) : GB4943.1-2011, PSB (Singapore ) : PSB+IEC60950-1, NOM (Mexico ) : NOM-001-SCFI-1993, IRAM (Argentina ) : IRAM+IEC60950-1, SASO (Saudi Arabia ) : SASO+IEC60950-1, BIS(India) : IEC60950-1 / IS13252, NOM(Mexico) : Tunerless : NOM-019-SCFI-1998, KC(Korea) : K 60950-1, EAC(Russia) : EAC+IEC60950-1, INMETRO(Brazil) : INMETRO+IEC60950-1, BSMI(Chinese Taiwan) : BSMI+IEC60950-1, RCM(Australia) : IEC60950-1/AS/NZS 60950-1, CSA (Canada) : cUL, UL(USA) : cUL60950-1, TUV (Germany) : CE, NEMKO (Norway) : CE
