High Performance by Twin BLDC Compressor
Twin BLDC Compressor
A key contributor to Samsung Free Joint Multi(FJM)'s efficiency is its advanced compressor technology. Adopting Twin Brushless Direct Current(BLDC) rotary compressor with premium moving parts, Samsung FJM delivers efficient and reliable performance.
* Please note that the product image in the picture may be different from the actual one.
Wide Operation Outdoor Temperature Range
Smart Inverter System
Samsung FJM cools in outdoor temperature in 46°C and warms in -15℃*, eliminating need for additional units to cope with adverse weather. Its smart inverter system delivers your set temperature quickly, and keeps performing fine-tune adjustments to ensure a constant, comfortable environment.
* Test condition in accordance with EN 14511-2:2011.** Please note that the product image in the picture may be different from the actual one.
Specifications
-
Capacity
27300Btu/hr
-
Capacity (Cooling, kW)
8.0kW
-
Capacity (Heating, kW)
9.0kW
-
Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)
880 x 798 x 310mm
-
Type
FREE JOINT MULTI
-
Outdoor Unit
AJ080TXJ4KH/EA
-
1,2,220~240,50/60
-
Mode
HEAT PUMP
-
4 HP
-
Cooling [kW]
8.0 kW
-
Cooling [Btu/h]
27,300 Btu/h
-
Heating [kW]
9.0 kW
-
Heating [Btu/h]
30,700 Btu/h
-
Cooling 1)
2.38 kW
-
Heating 2)
2.13 kW
-
Cooling 1)
10.9 A
-
Heating 2)
9.7 A
-
MCA [A]
18.2 A
-
MFA [A]
20.8 A
-
EER (Nominal Cooling)
3.36
-
COP (Nominal Heating)
4.23
-
Energy Grade (Cooling)
6.50(A++)
-
Energy Grade (Heating)
3.90(A)
-
Type
Twin BLDC Rotary
-
Output(kW)
7.77 kW
-
Model
G8T260FUAEW
-
Oil (Type)
POE
-
Oil (Initial Charge) [cc]
700 cc
-
Type
Propeller Fan
-
Motor (Output) [W]
125 W
-
Air Flow Rate (High / Mid / Low) [CMM]
55.4 CMM
-
Air Flow Rate(High/Mid/Low)[L/S]
923
-
Liquid Pipe (Ø,mm x EA)
6.35 x 4
-
Liquid Pipe (Ø,inch x EA)
1/4 x 4
-
Gas Pipe (Ø,mm x EA)
9.52 x 2 + 12.70 x 2
-
Gas Pipe (Ø,inch x EA)
3/8 x 2 + 1/2 x 2
-
Installation Max. Length [m]
70 m
-
Installation Max. Height [m]
15 m
-
Power Source Wire
2.5 ~ 2.5
-
Transmission Cable
0.75 ~ 1.5
-
Type
R410A
-
Factory Charging (kg)
2.8 kg
-
Factory Charging (tCO2e)
5.85 tCO2e
-
Sound Pressure
48 dBA
-
Sound Power
64 dBA
-
Net Weight(kg)
57.5 kg
-
Shipping Weight (kg)
62.0 kg
-
Net Dimensions (WxHxD) (mm)
880 x 798 x 310 mm
-
Shipping Dimensions (WxHxD) (mm)
1,023 x 896 x 413 mm
-
Cooling (℃)
-10.0 ~ 46.0 ℃
-
Heating (℃)
-15.0 ~ 24.0 ℃
