Flexibly fits & blends into more places
2-way Air InletInstall your air conditioner in a wide variety of locations. It has a 2-way air inlet – bottom or rear – that gives you much more flexibility in selecting an installation location. It can be configured to provide the optimum airflow to almost any room, while being concealed behind ceilings.
Blends in with a compact & elegant design
Slim & Compact Design (199mm Height)
Enhance the look and feel of almost any space. Being 199mm high and 700mm* wide, its slim and compact design is highly elegant, so it can be discretely concealed in many locations. It also makes installation, maintenance and repair quick and easy, so it’s ideal for a wide range of businesses.
* Based on the AM036KNLDEH/EU model. The width of other models may vary.
Automatically monitor filter cleanliness
Easy Filter Cleaning
Maintain your air conditioner easily and cost-effectively. The filter cleaning indicator automatically notifies you when the filter is due for cleaning after 1,000 hours of operation*. The design of the duct system makes this very simple, so it reduces maintenance time and its financial impact.
* 1,000 hours is the default setting, but this can be adjusted to 2,000 hours on the internal PCB.
Simple set up, automatically even cooling
Smart Pressure Control
Enjoy maximum comfort and efficiency with minimum effort. The Smart Pressure Control automatically optimizes the air volume and pressure and minimizes noise, ensuring consistent cooling and heating in any situation. The external static pressure (ESP) can also be adjusted using a remote control
Flexible installation in more locations
Optional High Lift-Up Drain Pump
Enjoy a greater choice of installation locations and maintain it conveniently. An optional High Lift-Up Drain Pump lifts condensed water up to 750mm, compared with the previous limit of 700mm. And you can check, repair or install a new drain pump by simply removing the right-side panel.
Specifications
-
Capacity
8530BTU/h
-
Capacity (Cooling, kW)
5.2kW
-
Capacity (Heating, kW)
5.6kW
-
Net Dimension (Outdoor, WxHxD, mm*mm*mm)
900 x 199 x 440mm
-
Type
Home Duct
-
Indoor Unit
AJ052TNLDKH/EA
-
1,2,220-240,50
-
Mode
HP
-
Cooling [kW]
5.2 kW
-
Cooling [Btu/h]
17,700 Btu/h
-
Heating [kW]
5.6 kW
-
Heating [Btu/h]
19,100 Btu/h
-
Cooling 1) [W]
50 W
-
Heating 2) [W]
50 W
-
Cooling 1)
0.45 A
-
Heating 2)
0.45 A
-
Type
Sirroco Fan / SSR
-
Motor (Output) [W]
84 x 1 W
-
Air Flow Rate (High / Mid / Low) [CMM]
14.0 / 9.8 / 5.4 CMM
-
Air Flow Rate(High/Mid/Low)[L/S]
233 / 163 / 90
-
External Static Pressure (Min / Std / Max) [mmAq]
0 / 2 / 5.1 mmAq
-
External Static Pressure (Min / Std / Max) [Pa]
0 / 19.6 / 50.0 Pa
-
Liquid Pipe (Φ, mm)
6.35 mm
-
Liquid Pipe (Φ, inch)
1/4
-
Gas Pipe (Φ, mm)
12.7 mm
-
Gas Pipe (Φ, inch)
1/2
-
Drain Pipe (Φ,mm)
VP25 (OD 32, ID 25)
-
Power Source Wire
1.5 ~ 2.5
-
Transmission Cable
0.75 ~ 1.50
-
Type
R410A
-
Control Method
EEV NOT INCLUDED
-
Sound Pressure
33 / 29 / 23 dBA
-
Sound Power
50 dBA
-
Net Weight(kg)
18.9 kg
-
Shipping Weight (kg)
21.8 kg
-
Net Dimensions (WxHxD) (mm)
900 x 199 x 440 mm
-
Shipping Dimensions (WxHxD) (mm)
1,151 x 280 x 544 mm
-
Air Filter
Removable / Washable
