Application

Client PCs

Kapacitet

4,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

Formfaktor

2.5 inch

Brugergrænseflade

SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface

Dimension (WxHxD)

100 X 69.85 X 6.8 (mm)

Vægt

Approx. 48.0g Weight

Lagerhukommelse

Samsung V-NAND 3bit MLC

Styreenhed

Samsung MKX Controller

Cache-hukommelse

Samsung 4 GB Low Power DDR4 SDRAM

TRIM understøttelse

TRIM Supported

S.M.A.R.T Support

S.M.A.R.T Supported

GC (Garbage Collection)

Auto Garbage Collection Algorithm

Encryption Support

AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive)

WWN Support

World Wide Name supported

Device Sleep Mode Support

Ja

Sekventiel læsning

Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration

Sekventiel skrivning

Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Random Read (4KB, QD32)

Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Random Write (4KB, QD32)

Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Random Read (4KB, QD1)

Up to 13,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Random Write (4KB, QD1)

Up to 36,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated

Average Power Consumption (system level)

Average: 2.5 W *Maximum: 5.0 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration

Power consumption (Idle)

Max. 35 mW * Actual power consumption may vary depending on system hardware & configuration

Tilladt spænding

5V ± 5% Allowable voltage

Pålidelighed (MTBF)

1.5 Million Hours Reliability (MTBF)

Omgivelsestemperatur (drift)

0 - 70 ℃ Operating Temperature

Stød

1,500 G & 0.5 ms (Half sine)

Installation Kit

Not Available

Management SW

Magician Software for SSD management, Data Migration Software for SSD upgrade
