Interaktivní displej QB13R-T

LH13QBRTBGCXEN

  • Úhlopříčka 13“
  • Rozlišení 1920*1080 (Full HD)
  • Jas 300 nit

Velikost úhlopříčky

Interaktivní displej QB13R-T

13"

Improved engagement with intuitive interaction

Samsung’s QB13R-T touch-enabled small display provides a unique store experience and improves customer engagement, offering customers content up close in a compact design. Designed for professional use, it enables efficient content operation and reliable performance for any business use.

Improved engagement with intuitive interaction Improved engagement with intuitive interaction

Fast, effective touch capabilities

With integrated capacitive touch functionality, the QB13R-T provides a user-friendly experience. Its 10-point multi-touch and fast response time powers an intuitive interface that allows for customer-driven search and action, creating new customer interactions and driving purchase.

Fast, effective touch capabilities Fast, effective touch capabilities

Crisp and visible content

The display supports 1920x1080 FHD resolution, displaying crisp and easy-to-read content. This is enhanced by a non-glare panel which always delivers clear content in any ambient light. These innovative features are supported by reliable 16/7 operation, suitable for professional use.

Crisp and visible content Crisp and visible content

Slim, smart design

The compact and slim design of the QB13R-T allows for efficient space utilization, even in compact locations. A sleek back design makes the display optimal for both wall mounting or simply standing, while the connectivity, content play and device controls are easy to operate.

Slim, smart design Slim, smart design

Powerful content playback

With an embedded MagicINFO S player, backed by TIZEN, the QB13R-T allows efficient and seamless playback without any external media player. SSSP also allows easy content development through reinforced compatibility with multiple web formats.

Powerful content playback Powerful content playback

Comprehensive security setup

The powerful Knox security system provides rigid, three-layer security, offering airtight protection at the application, platform and system level, while restricting access to content and hardware. In addition, remote control of the network and USB ports prevents any unauthorized access.

Comprehensive security setup Comprehensive security setup

Convenient, clean display control

With center IR, each display receives IR signals direct to the panel, allowing easy and convenient remote control even with a tailored installation. When mounted, display doesn't require an IR receiver cabling extension. Built-in Wi-Fi allows wireless remote management for both content and display.

Convenient, clean display control Convenient, clean display control

Safe operation, reliable performance

The QB13R-T is electromagnetic compatibility (EMC) class B compliant, meeting strict safety and reliability standards for operation. Additionally, IP5x rating ensures durable performance even in dusty environments.

Safe operation, reliable performance Safe operation, reliable performance

* IP5x : Product operation is not guaranteed when exposed to particular types of dust, such as metal dust.

Specifikace

Displej

  • Úhlopříčka 13"
  • Typ panelu ADS
  • Rozlišení 1,920 x 1,080
  • Rozteč pixelů (H x V) 0.153 (H) x 0.153 (V)
  • Jas (typický) 250
  • Kontrastní poměr 600:1
  • Úhel sledování (H/V) 178/178
  • Čas odezvy (ms) 8ms
  • Barevný gamut 45%
  • Zatmavení displeje 25%, 10%(glass)
  • Horizontální frekvence 30~81kHz
  • Maximální frekvence pixelů 594MHz
  • Vertikální frekvence 48~75Hz
  • Contrast Ratio (Dynamic) 10000:1

Konektivita

  • HDMI vstup 1
  • DisplayPort vstup No
  • USB 2
  • IR vstup No
  • HDBaseT vstup No
  • Audio vstup No
  • Audio výstup Stereo Mini Jack
  • Video výstup No
  • RS232 vstup Yes
  • RS232 výstup No
  • RJ45 vstup Yes
  • RJ45 výstup No
  • WiFi Yes
  • 3G Dongle No

Napájení

  • Zdroj napájení AC100-240V 50/60Hz
  • Spotřeba energie (režim zapnuto) 27.5W
  • Spotřeba energie (režim spánku) 0.5 W

Rozměry

  • Rozměry sady (ŠxVxH) 322 x 193.5 x 29.8 mm
  • Rozměry balení (ŠxVxH) 376 x 132 x 248 mm

Váha

  • Váha sady 1.1 kg
  • Hmotnost balení 2.0 kg

Provozní podmínky

  • Teplota 0℃~ 40℃
  • Vlhkost 10 ~ 80%, non-condensing

Mechanické specifikace

  • Podpora VESA 100 x 100 mm
  • Šířka rámečku 13.1
  • Materiál rámečku Non-Glossy

Obecná funkce

  • Externí paměťový slot No

Volitelné funkce

  • Držák No
  • Stojan Inbox(Simple Stand) (2ea)

Interní přehrávač (MagicInfo)

  • Podpora MagicInfo Daisychain videozdi No

Ekologie

  • Energetická třída B

Certifikace a shoda

  • Třída bezpečnosti Class B FCC (USA) Part 15, Subpart B   KCC/EK (Korea) Tuner : KN32 / KN35   Tunerless : KN32 / KN35 CE (Europe) EN55032 : 2012 or 2015   EN55024:2010 or EN 55035:2017 VCCI (Japan) VCCI CISPR32:2016   CCC(China) GB/T9254-2008   GB17625.1-2012 BSMI (Taiwan) CNS13438 ( ITE EMI ) CNS14336-1 ( ITE Safety ) CNS15663 (RoHS)   C-Tick (Australia) AS/NZS CISPR32:2015   GOST(Russia/CIS) ROCT CISPR 24-2013   ROCT CISPR 22:2005
  • Bezpečnost CB (Europe) : IEC60950-1/EN60950-1CCC (China) : GB4943.1-2011PSB (Singapore ) : PSB+IEC60950-1NOM (Mexico ) : NOM-001-SCFI-1993IRAM (Argentina ) : IRAM+IEC60950-1SASO (Saudi Arabia ) : SASO+IEC60950-1BIS(India) : IEC60950-1 / IS13252NOM(Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998KC(Korea) : K 60950-1EAC(Russia) : EAC+IEC60950-1INMETRO(Brazil) : INMETRO+IEC60950-1BSMI(Taiwan) : BSMI+IEC60950-1RCM(Australia) : IEC60950-1/AS/NZS 60950-1UL(USA) : cUL60950
