9100 PRO NVMe M.2 SSD - 4TB

MZ-VAP4T0B/AM

4.7 ( 3 )

Choose your Colour

Colour :

Choose your Memory

9100 PRO NVMe M.2 SSD - 4TB
Black 4 TB

Add to cart Where to buy

Features

Performance ready for a new era

Top 2 features

PCIe® 5.0 Performance PCIe® 5.0 Performance

PCIe® 5.0 Performance

Max 14,800/13,400 MB/s sequential speeds,two times faster than 990 PRO.

Innovative Power & Thermal Control Innovative Power & Thermal Control

Innovative Power & Thermal Control

Up to 49% enhanced power efficiencywith advanced thermal control.

Breakthrough PCIe® 5.0 performance

Push PCIe® 5.0 performance to the max. 9100 PRO achieves lightning-fast sequential read/write speeds up to 14,800/13,400 MB/s, two times faster than 990 PRO. Leave Gen4 limits behind with random read/write speeds up to 2,200K/2,600K IOPS, only possible by Gen5.1

With the 9100 PRO, it says "up to 2x faster", "PCIe® 5.0". Below that, it says "Sequential Read up to 14,800 MB/s", "Sequential Write up to 13,400 MB/s" with icons indicating Sequential speed, and "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" with icons indicating Random speed. With the 9100 PRO, it says "up to 2x faster", "PCIe® 5.0". Below that, it says "Sequential Read up to 14,800 MB/s", "Sequential Write up to 13,400 MB/s" with icons indicating Sequential speed, and "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" with icons indicating Random speed.

Every task, powerfully parallel

Speed past productivity limits. Exhilarating random read/write speeds enable ultra-fast parallel processing for countless fragmented data, at up to 2,200K/2,600K IOPS. Experience superior output and instant loads for huge games, high-performance tasks, and even AI applications.

Several puzzle pieces are coming together. It says "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" along with an icon indicating Random speed. Several puzzle pieces are coming together. It says "Random Read up to 2,200K IOPS", Random Write up to 2,600K IOPS" along with an icon indicating Random speed.

Extraordinary thermal efficiency

Peak performance, uninterrupted. The advanced 5nm controller power architecture enhances power efficiency up to 49% over 990 PRO. Exceptional thermal control ensures nothing disrupts your flow, so you can keep the most demanding programs running with the max possible power of PCIe® 5.0.2

The detailed components that make up the 9100 PRO are visible. There are two components that say "SAMSUNG V-NAND" and one each that says "SAMSUNG DRAM" and "SAMSUNG Controller." Around it, an arrow indicating the direction in which heat is emitted is visible, and "Nickel coated controller" and "Heat spreader label" are written. On one side again, "Thermal Control" is written with the icon, which means temperature control. The detailed components that make up the 9100 PRO are visible. There are two components that say "SAMSUNG V-NAND" and one each that says "SAMSUNG DRAM" and "SAMSUNG Controller." Around it, an arrow indicating the direction in which heat is emitted is visible, and "Nickel coated controller" and "Heat spreader label" are written. On one side again, "Thermal Control" is written with the icon, which means temperature control.

Conquer any game instantly

Boundless gaming freedom. Join forces with the 9100 PRO with Heatsink on PC, laptop, or PlayStation® 5, and experience otherworldly performance with the latest PCIe® 5.0 interfaces. Equip yourself with the ultimate winning edge to devastate opponents and reign supreme. Any arena, any device.4

Various examples of playing games through desktop PCs and console game consoles are shown. Various examples of playing games through desktop PCs and console game consoles are shown.

Slim build. Seamless fit.

Super slim fit. 9100 PRO with Heatsink boasts an incredibly thin 8.8mmT body, compatible with PlayStation® 5, PC, and on laptops, meeting PCI-SIG® D8 specs. Overcome space limits and get ultimate design flexibility to build your most efficient, high-performance system, with the compact M.2 form factor.5

A close-up of a section of the 9100 PRO with Heatsink, showing its thinness via arrows. It says "8.8mmT". Below that are icons for desktop PCs and the text "Desktop PC in 1/2/4TB with 8.8mmT", icons for laptops and the text "Laptop in 1/2/4TB with 8.8mmT", and icons for consoles and the text "PlayStation® 5 in 1/2/4TB with 8.8mmT, In 8TB with 11.25mmT". A close-up of a section of the 9100 PRO with Heatsink, showing its thinness via arrows. It says "8.8mmT". Below that are icons for desktop PCs and the text "Desktop PC in 1/2/4TB with 8.8mmT", icons for laptops and the text "Laptop in 1/2/4TB with 8.8mmT", and icons for consoles and the text "PlayStation® 5 in 1/2/4TB with 8.8mmT, In 8TB with 11.25mmT".

Specifications

  • Interface

    PCIe® 5.0 x4, NVMe™ 2.0

  • Sequential Read

    Up to 14,800 MB/s * Performance may vary based on system hardware & configuration

  • Sequential Write

    Up to 13,400 MB/s * Performance may vary based on system hardware & configuration

  • Warranty

    5-year Limited Warranty or 2,400TBW Limited Warranty

  • Application

    Client PCs, Game Consoles

  • Weight

    Max 9.0g Weight

  • Dimension (WxHxD)

    Max 80.15 x Max 22.15 x Max 2.38 mm

  • Application

    Client PCs, Game Consoles

  • Capacity

    4,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

  • Form Factor

    M.2 (2280)

  • Interface

    PCIe® 5.0 x4, NVMe™ 2.0

  • Dimension (WxHxD)

    Max 80.15 x Max 22.15 x Max 2.38 mm

  • Weight

    Max 9.0g Weight

  • Storage Memory

    Samsung V-NAND TLC

  • Controller

    Samsung in-house Controller

  • Cache Memory

    Samsung 4GB Low Power DDR4X SDRAM

  • TRIM Support

    Supported

  • S.M.A.R.T Support

    Supported

  • GC (Garbage Collection)

    Auto Garbage Collection Algorithm

  • Encryption Support

    AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)

  • WWN Support

    Not supported

  • Device Sleep Mode Support

    Yes

  • Sequential Read

    Up to 14,800 MB/s * Performance may vary based on system hardware & configuration

  • Sequential Write

    Up to 13,400 MB/s * Performance may vary based on system hardware & configuration

  • Random Read

    Up to 2,200,000 IOPS * Performance may vary based on system hardware & configuration

  • Random Write

    Up to 2,600,000 IOPS * Performance may vary based on system hardware & configuration

  • Average Power Consumption (system level)

    Average: Read 9.0 W / Write 8.2 W* Actual power consumption may vary depending on system hardware & configuration

  • Power consumption (Idle)

    Typical 6.5 mW * Actual power consumption may vary depending on system hardware & configuration

  • Power Consumption (Device Sleep)

    Typical 5.7 mW * Actual power consumption may vary depending on system hardware & configuration

  • Allowable Voltage

    3.3 V ± 5 % Allowable voltage

  • Reliability (MTBF)

    1.5 Million Hours Reliability (MTBF)

  • Operating Temperature

    0 - 70 ℃ Operating Temperature

  • Shock

    1,500 G & 0.5 ms (Half sine)

  • Installation Kit

    Not Available

  • Management SW

    Magician Software for SSD management

  • 5-year Limited Warranty or 2,400TBW Limited Warranty

Product support

Find answers to the questions you have about the product

Product support

Get the most from Samsung device and services.

Learn more

Recently viewed

9100 PRO NVMe M.2 SSD - 4TB

$769.99

From $24.84/mo for 36 mos or $769.99

  • 1. *Sequential and random write performance was measured with Intelligent Turbo Write technology activated, which only operates within a specific data transfer size. Performance may vary depending on SSD’s firmware, system hardware & configuration and other factors. For detailed information, please contact your local service center.

    **To maximize the performance of the 9100 PRO, please check whether your system supports PCIe® 5.0 on Intel or AMD website. Go to feature
  • 2. *Image shown for illustrative purposes only.

    **990 PRO sequential read/write 1,221/1,255 MB/s per Watt, 9100 PRO sequential read/write 1,822/1,703 MB/s per Watt based on the internal test result of the 2TB capacity model. Go to feature
  • 3. *For detailed information, please visit Samsung Magician software website.https://semiconductor.samsung.com/consumer-storage/magician/ Go to feature
  • 4. *For M.2 SSD requirements for PlayStation® 5, please visit https://www.playstation.com/support/hardware/ps5-install-m2-ssd/ Go to feature
  • 5. *Heatsink in 1/2/4TB with 8.8mmT fits to laptop, desktop PC and PlayStation® 5.

    **In 8TB with 11.25mmT fits to PlayStation® 5.

    ***For M.2 SSD requirements for PlayStation® 5, please visit https://www.playstation.com/support/hardware/ps5-install-m2-ssd/

    ****Image shown for illustrative purposes only. Actual usage environment may vary. Go to feature

All specifications and descriptions provided herein may be different from the actual specifications and descriptions for the product. Samsung reserves the right to make changes to this document and the product described herein, at anytime, without obligation on Samsung to provide notification of such change.
