980 PCIe 3.0 NVMe M.2 SSD 250GB
250 GB

Where to buy

Highlights

Up to 3,500 MB/s Seq. Read

Up to 3,500 MB/s Seq. Read

Up to 3,000 MB/s Seq. Write

Up to 3,000 MB/s Seq. Write

V-NAND

V-NAND

5 year Limited Warranty

5 year Limited Warranty

Features

Upgrade to breathtaking NVMe speed

It's time to maximise your PC's potential with our SSD 980. Whether you need a boost for gaming or a seamless workflow for heavy graphics, the 980 is the smart choice for outstanding SSD performance, and it's backed by an NVMe interface and PCIe 3.0 technology.

. .

* The NVM Express® design mark is a registered trademark of NVM Express, Inc.

Packed with speed

Get right to it. The 980 harnesses nearly all the speed advantages of PCIe 3.0 through HMB* technology and NVMe efficiency. The DRAM-less design delivers exceptional value, achieving breakneck sequential read/write speeds up to 3,500/3,000 MB/s**, and over 6.2x*** the speed of SATA SSDs.

Packed with speed Packed with speed

*HMB (Host Memory Buffer) technology enables the SSD to use the DRAM of the host system for read/write caching and buffering.
**Performance may vary depending on the SSD’s firmware version, system and hardware configuration. Performance measurements are based on IOmeter 1.1.0. The write performances were measured with Intelligent TurboWrite technology activated. Intelligent TurboWrite operates only within a specific data transfer size. For detailed information, please contact your local service center. Test system configuration: Intel(R) Core(TM) i7-6700K CPU @ 4.00GHz,DDR4 2133MHz 8GBx2 OS-Windows 10 Pro 64bit Asrock Z-170 Extreme7+.
***Results are based on a comparison with Samsung SATA SSDs.

Keep moving with Full Power Mode

Keep your SSD running for consistent high performance with Full Power Mode. Switch on the Samsung Magician software to always keep your SSD in active mode and instantly jump between intensive work with huge files, graphics-heavy games and normal PC usage.

. .

Built for the long run

Keep your files safe with an SSD that's in it for the long haul. Rest assured with up to 600 TBW* and a 5-year limited warranty**. The 980's optimised endurance comes with reliability, thanks to Samsung's in-house solutions, from the state-of-the-art controller to V-NAND and the latest firmware.

. .

*TBW : Terabytes written
** Warrantied TBW for 980: 150 TBW for 250GB model, 300 TBW for 500GB model, 600 TBW for 1TB model.* 5 years or TBW, whichever comes first. For more information on the warranty, please find the enclosed warranty statement in the package.

Reliable thermal control

High-performance SSDs usually require high-performance thermal control. To ensure stable performance, the 980 uses nickel coating to help manage the controller's heat level and a heat spreader label to deliver effective thermal control of the NAND chip.

. .

Smart thermal solution

Embedded with Samsung's cutting-edge thermal control algorithm, the 980 manages heat on its own to deliver durable and reliable performance. Samsung's Dynamic Thermal Guard technology maintains the 980's temperature at optimal levels to minimize performance fluctuations in the long haul.

. .

Samsung Magician software

Unlock the full power of the 980 with Samsung Magician's intuitive yet advanced optimization tools. Monitor drive health, optimize performance, protect valuable data, and receive important updates with Magician to ensure you're always getting the best performance out of your SSD.

. .

World's No. 1* Flash Memory

Experience superior performance and reliability from the world's number one brand for flash memory seller since 2003. All firmware and components, including Samsung's world-renowned DRAM and NAND, are produced in-house, allowing end-to-end integration for quality you can trust.

*Source: 2003-2019 IHS Markit data: NAND suppliers' revenue market share.

World's No. 1* Flash Memory World's No. 1* Flash Memory

*Source: 2003-2019 IHS Markit data: NAND suppliers' revenue market share.

Specifications

  • Interface

    PCIe Gen 3.0 x4, NVMe 1.4

  • Sequential Read

    Up to 2,900 MB/s * Performance may vary based on system hardware & configuration

  • Sequential Write

    Up to 1,300 MB/s * Performance may vary based on system hardware & configuration

  • Warranty

    5-Year Limited Warrantyor 150 TBW Limited Warranty

  • Application

    Client PCs

  • Weight

    Max 8.0 g Weight

  • Dimension (WxHxD)

    80.15 x 22.15 x 2.38 (mm)

  • Application

    Client PCs

  • Rated Capacity

    250GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

  • Form Factor

    M.2 (2280)

  • Interface

    PCIe Gen 3.0 x4, NVMe 1.4

  • Dimension (WxHxD)

    80.15 x 22.15 x 2.38 (mm)

  • Weight

    Max 8.0 g Weight

  • Storage Memory

    Samsung V-NAND 3-bit MLC

  • Controller

    Samsung Pablo Controller

  • Cache Memory

    HMB(Host Memory Buffer)

  • TRIM Support

    Supported

  • S.M.A.R.T Support

    Supported

  • GC (Garbage Collection)

    Auto Garbage Collection Algorithm

  • Encryption Support

    AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)

  • WWN Support

    Not supported

  • Device Sleep Mode Support

    Yes

  • Sequential Read

    Up to 2,900 MB/s * Performance may vary based on system hardware & configuration

  • Sequential Write

    Up to 1,300 MB/s * Performance may vary based on system hardware & configuration

  • Random Read (4KB, QD32)

    Up to 230,000 IOPS * Performance may vary based on system hardware & configuration

  • Random Write (4KB, QD32)

    Up to 320,000 IOPS * Performance may vary based on system hardware & configuration

  • Random Read (4KB, QD1)

    Up to 17,000 IOPS * Performance may vary based on system hardware & configuration

  • Random Write (4KB, QD1)

    Up to 53,000 IOPS * Performance may vary based on system hardware & configuration

  • Average Power Consumption (system level)

    *Average: 3.7 W*Maximum: 5.6 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration

  • Power consumption (Idle)

    Max. 45 mW * Actual power consumption may vary depending on system hardware & configuration

  • Allowable Voltage

    3.3 V ± 5 % Allowable voltage

  • Reliability (MTBF)

    1.5 Million Hours Reliability (MTBF)

  • Operating Temperature

    0 - 70 ℃ Operating Temperature

  • Shock

    1,500 G & 0.5 ms (Half sine)

  • Installation Kit

    Not Available

  • Management SW

    Magician Software for SSD management

  • 5-Year Limited Warrantyor 150 TBW Limited Warranty
