Choose Memory

960 EVO NVMe M.2 SSD
500 GB

Sorry! This product is no longer available

Highlights

V-NAND

V-NAND

Turbo Write

Turbo Write

3,500MB/s Seq. Read

3,500MB/s Seq. Read

2,100MB/s Seq. Write

2,100MB/s Seq. Write

Features

The smart choice in NVMe SSDs

Discover the next advancement in Samsung SSD technology with our high-performance, highly reliable 960 EVO Series NVMe M.2 SSDs. Non-Volatile Memory Express (NVMe) with a new Polaris controller outperforms our SATA SSDs with exceptionally fast read/write speeds, and Samsung TurboWrite technology which helps accelerate write speeds even further. Samsung's Magician software solution is designed to provide advanced functionality to manage, monitor and optimise drive performance.
v-nand icon
960 EVO
960 EVO

Designed to raise your performance expectations

The Samsung SSD 960 EVO offers storage for smart consumers who want an experience beyond what the Samsung SATA interface can provide. An enhanced bandwidth, provided by the NVMe interface, combined with the new Polaris controller, helps to facilitate sequential R/W speeds up to 3,200/1,900 MB/s and random R/W speeds up to 380/360K IOPS, respectively. Plus, the new Intelligent TurboWrite technology is designed to accelerate write speeds even further*.
*Sequential performance measurements based on CrystalDiskMark 5.0.2/IOmeter 1.1.0 and random performance measurements based on IOmeter 1.1.0.Performance may vary based on the SSD`s firmware version,system hardware and configuration.Test system configuration: Intel® Core i7-6700K CPU@4.0 GHz,DDR4 1700MHz 16GB,OS-Window 10 Pro x64,Chipset-ASROCK Z170 EXTREME 7.
Sequential write performance measurements based on Intelligent TurboWrite technology.The sequential write performances after Intelligent TurboWrite region are 300 MB/s(250GB),600 MB/s(500GB) and 1200 MB/s(1TB). Sequential read up to 3,300 MB/s,Sequential write up to 1,900 MB/s, nvme.
Sequential read up to 3,300 MB/s,Sequential write up to 1,900 MB/s, nvme
Sequential read up to 3,300 MB/s,Sequential write up to 1,900 MB/s, nvme

Rest easy with solid reliability

Great performance is not measured by speed alone. How long the performance can be sustained is also important. The 960 EVO holds its own by boasting up to 400 TBW* for the 1TB model. Dynamic Thermal Guard helps prevent overheating, designed to protect the data and ensure optimal responsiveness. It's all backed by a 3-year limited warranty**.
*TBW : Terabytes Written ** See http://www.samsung.com/au/support/warranty/ for further details.
TBW 400 Terabytes, Dynamic Thermal Guard
TBW 400 Terabytes, Dynamic Thermal Guard

Manage your drive like magic

The Samsung SSD 960 EVO comes with the newly upgraded Magician—an advanced software solution helping users to monitor, manage and maintain the drive. Magician is designed to provide personalised firmware checking and additional functions tailored for individual user's drives. It even updates the firmware automatically to make sure that the drive's performance stays up to date.
Magician software solution
Magician software solution

Specifications

  • Application

    Client PCs

  • Interface

    PCIe 3.0 x4, NVMe 1.2

  • Dimension (WxHxD)

    Max. 80.15 x 22.15 x 2.38 (mm)

  • Weight

    Max 8 g

  • Sequential Read

    Up to 3,200 MB/sec *Performance may vary based on system hardware & configuration

  • Sequential Write

    Up to 1,800 MB/sec *Performance may vary based on system hardware & configuration

  • Application

    Client PCs

  • Rated Capacity

    500 GB (1 GB=1 Billionbyte by IDEMA) *Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

  • Form Factor

    M.2

  • Interface

    PCIe 3.0 x4, NVMe 1.2

  • Dimension (WxHxD)

    Max. 80.15 x 22.15 x 2.38 (mm)

  • Weight

    Max 8 g

  • NAND Type

    Samsung V-NAND

  • Controller

    Samsung Polaris controller

  • Cache Memory

    Samsung 512 MB Low Power DDR3

  • TRIM Support

    TRIM Supported

  • S.M.A.R.T Support

    S.M.A.R.T Supported

  • GC (Garbage Collection)

    Auto Garbage Collection Algorithm

  • Encryption Support

    AES 256-bit for User Data Encryption, TCG Opal

  • Device Sleep Mode Support

    5mW(L1.2)

  • Sequential Read

    Up to 3,200 MB/sec *Performance may vary based on system hardware & configuration

  • Sequential Write

    Up to 1,800 MB/sec *Performance may vary based on system hardware & configuration

  • Random Read (4KB, QD32)

    Up to 330,000 IOPS (Thread 4) *Performance may vary based on system hardware & configuration

  • Random Write (4KB, QD32)

    Up to 330,000 IOPS (Thread 4) *Performance may vary based on system hardware & configuration

  • Random Read (4KB, QD1)

    Up to 14,000 IOPS (Thread 1) *Performance may vary based on system hardware & configuration

  • Random Write (4KB, QD1)

    Up to 50,000 IOPS (Thread 1) *Performance may vary based on system hardware & configuration

  • Power Consumption

    *Average: Typ. 5.4 Watts, Idle : 40mW *Actual power consumption may vary depending on system hardware & configuration

  • Reliability (MTBF)

    1.5 Million Hours Reliability (MTBF)

  • Operating Temperature

    0°C to 70°C (Measured by SMART Temperature. Proper airflow recommended)

  • Shock

    1,500 G , duration 0.5 m sec, 3 axis

  • Management SW

    Magician Software for SSD management

  • Not Available

  • 3 Year Limited Warranty or 200TBW Limited Warranty
