Impactful Visuals
Extreme-Narrow Bezels
With a narrow bezel measuring just 1.74mm, the VHB-E delivers an impactful visual experience. Create an immersive, captivating and dependable viewing experience.
Modern, slim design
Slender Depth
The slender design and 70.4mm cabinet depth1 provides flexibility for installation and is intended to save space. With an aesthetically appealing design, this display creates a clean, modern look for retail or other public spaces.
1 Exact depth varies by display size.
View content from a variety of angles
Wide Viewing Angles
The VHB-E’s wide viewing angles mean content is easily visible to viewers, even when not standing directly in front of the display. This helps to deliver audiences clear information in a range of layouts and locations.
* Images simulated for illustrative purposes only.
Brilliant images
Anti-Glare Panels and 700 nit Brightness
Immerse yourself in brilliant image presentation with 700 nit brightness. Anti-glare panels help deliver incredible visibility in multiple light conditions. Combined with a high contrast ratio, this helps to deliver sharp images to audiences 24/7.
* Images simulated for illustrative purposes only.
Image enhancement
Picture Enhancer and Black Equaliser
Samsung’s powerful picture enhancement technology is designed to deliver vibrant and clear content. Picture Enhancer mode improves colour saturation and contrast. Using Black Equaliser mode dark images are lightened, illuminating details and helping make details easier to see.
* Images simulated for illustrative purposes only.
Convenient mobile calibration
Colour Expert Pro Mobile Solution
Samsung’s Colour Expert Pro mobile solution2 provides quick and easy Video Wall calibration through a compatible mobile camera. With the solution’s intuitive UI, even non-expert users can adjust the video wall’s white balance simultaneously without the need for additional equipment.
2 Mobile is required. Compatible with Samsung Galaxy S8, Samsung Glaxy Note 8, Samsung Galaxy S9 and later models.
Display 4K UHD content
Daisy Chain and Optional Signage Player Box
Samsung video walls provide an impressive 4K UHD viewing experience with minimal effort. With daisy chain design utilising Display Port 1.2 and HDMI ports, when four compatible units are combined, the display can project 4K UHD content across multiple screens3.
With no external graphic card or UHD splitters required, Samsung's UHD Signage Player Box streamlines functionality by combining the media player and content management software.
3 Four compatible screens (sold individually) are required to be connected to create UHD display. Signage Player Box also sold separately.
Industry standard certified
The VHB-E series is EMC4 class B compliant, meeting strict standards of electromagnetic wave emission, while IP5X certification5 protects the display against dust. The display packaging is also ISTA-certified6, minimising damage during delivery.
4 EMC: Electromagnetic compatibility.
5 IP5X validation ensures satisfactory operation even with a certain level of dust inside the product. However, product operation is not guaranteed when exposed to particular types of dust, such as metal dust.
6 ISTA: International Safe Transit Association.
Specifications
Specifications Detail
Display
- Diagonal Size 55"
- Panel Type IPS
- Resolution 1,920 x 1,080
- Pixel Pitch (HxV) 0.63x0.63
- Brightness (Typ) MAX 700 nit
- Contrast Ratio⁵ 1,000:1
- Viewing Angle (H/V) 178/178
- Response Time 8ms
- Colour Gamut 72 %
- Glass Haze 0.28 %
- H-Scanning Frequency 57.3kHz ~ 70kHz
- Maximum Pixel Frequency 78MHz
- V-Scanning Frequency 47Hz ~ 63Hz
- Contrast Ratio (Dynamic) 140,000:1
- Operation Time Support 24/7
Connectivity
- HDMI In 2
- DP In 1
- DVI In 1
- Version of HDMI 2
- Version of DP 1.2
- Version of HDCP 2.2
- USB 1
- IR In Yes
- Audio In Yes
- Audio Out Stereo Mini Jack
- Video Out Yes
- Power Out No
- RS232 In Yes
- RS232 Out Stereo Mini Jack
- RJ45 In Yes
- WiFi No
Power
- Power Supply AC100-240V 50/60Hz
- Power Consumption (On Mode) 250 W
- Power Consumption (Sleep Mode) 0.5 W
Dimension
- Set Dimension (WxHxD) 1212.2 x 683.0 x 70.4 mm
- Package Dimension (HxWxD) 1398 x 844 x 257 mm
Weight
- Net Weight 19.5 kg
- Package Weight 27 kg
Operation Conditions
- Temperature 0℃~ 40℃
- Humidity 10 ~ 90%
Mechanical Specification
- VESA Mount 600 x 400 mm
- Bezel Width B2B : 1.74mm (Panel Bezel to Panel Bezel), 1.3mm(U/L), 0.44mm(R/B) A2A : 2.49mm (Active area to Active area), 1.75mm(U/L), 0.74mm(R/B)
- Frame Material Glossy
Optional Feature
- Mount Yes
- Stand No
Certification and Compliance
- EMC FCC (USA) Part 15, Subpart B Class B CE (Europe) : EN 55032:2015+A11:2020 / EN 55035:2017+A11:2020 / EN IEC 61000-3-2:2019 / EN 61000-3-3:2013+A1:2019 VCCI (Japan) : VCCI-CISPR32 : 2015 KC (Korea) : KS C 9832 / KS C 9835 RCM (Australia/ Newzealand) : AS/NZS CISPR32:2015 CCC (China) : GB/T 9254-2008, GB 17625.1-2012 BSMI (Taiwan) : CNS 13438
- Safety CB (Europe) : IEC62368-1/EN62368-1 CCC (China) : GB 4943.1-2011 (Singapore ) : PSB+IEC62368-1NOM (Mexico ) : Tunerless : NOM-019-SCFI-1998IRAM (Argentina ) : IRAM+IEC62368-1 SIRC (Saudi Arabia ) : SASO+IEC62368-1 BIS (India) : IEC60950-1 / IS13252KC (Korea) : K 60950-1EAC (Russia) : EAC+IEC60950-1 BSMI (Taiwan) : BSMI+IEC60950-1 RCM(Australia) : IEC62368-1/AS/NZS 62368-1 UL (USA) : cUL62368-1 CSA (Canada) : cUL
Support
Find answers to your questions about the product
-
Quick Guide
- ver 2205040
- 1.96 MB
- Aug 05. 2022
ENGLISH, VIETNAMESE, ARABIC, PORTUGUESE, FRENCH, CHINESE(Traditional) -
User Manual
- ver 2204180
- 11.54 MB
- Aug 05. 2022
ENGLISH, VIETNAMESE, ARABIC, PORTUGUESE, FRENCH, CHINESE(Traditional)
